RM0090
Bit 3 CSBF: Clear standby flag
This bit is always read as 0.
0: No effect
1: Clear the SBF Standby Flag (write).
Bit 2 CWUF: Clear wakeup flag
This bit is always read as 0.
0: No effect
1: Clear the WUF Wakeup Flag after 2 System clock cycles
Bit 1 PDDS: Power-down deepsleep
This bit is set and cleared by software. It works together with the LPDS bit.
0: Enter Stop mode when the CPU enters deepsleep. The regulator status depends on the
LPDS bit.
1: Enter Standby mode when the CPU enters deepsleep.
Bit 0 LPDS: Low-power deepsleep
This bit is set and cleared by software. It works together with the PDDS bit.
0: Voltage regulator on during Stop mode
1: Voltage regulator in low-power mode during Stop mode
5.4.3

PWR power control/status register (PWR_CSR)

Address offset: 0x04
Reset value: 0x0000 0000 (not reset by wakeup from Standby mode)
Additional APB cycles are needed to read this register versus a standard APB read.
31 30 29
15 14 13
VOS
RDY
Res
r
Bits 31:15 Reserved, must be kept at reset value.
Bit 14 VOSRDY: Regulator voltage scaling output selection ready bit
0: Not ready
1: Ready
Bits 13:10 Reserved, must be kept at reset value.
Bit 9 BRE: Backup regulator enable
When set, the Backup regulator (used to maintain backup SRAM content in Standby and
V
SRAM can still be used but its content will be lost in the Standby and V
the application must wait that the Backup Regulator Ready flag (BRR) is set to indicate that
the data written into the RAM will be maintained in the Standby and V
0: Backup regulator disabled
1: Backup regulator enabled
Note: This bit is not reset when the device wakes up from Standby mode, by a system reset,
28 27 26 25
12 11 10 9
BRE
Reserved
rw
modes) is enabled. If BRE is reset, the backup regulator is switched off. The backup
BAT
or by a power reset.
Doc ID 018909 Rev 4
24 23 22 21
Reserved
Res.
8 7 6
EWUP
Reserved
Res.
rw
Power controller (PWR)
20 19 18
5 4 3 2
BRR PVDO
r r
modes. Once set,
BAT
modes.
BAT
17 16
1 0
SBF WUF
r r
108/1422
