General-purpose timers (TIM2 to TIM5)

The input stage samples the corresponding TIx input to generate a filtered signal TIxF.

Then, an edge detector with polarity selection generates a signal (TIxFPx) which can be

used as trigger input by the slave mode controller or as the capture command. It is

prescaled before the capture register (ICxPS).

Figure 144. Capture/compare channel (example: channel 1 input stage)

The output stage generates an intermediate waveform which is then used for reference:

OCxRef (active high). The polarity acts at the end of the chain.

read_in_progress

Capture/Compare Preload Register

capture_transfer

Capture/Compare Shadow Register

Doc ID 018909 Rev 4

TI1F_Falling

(from channel 2)

TI2F_falling

(from channel 2)

MCU-peripheral interface

compare_transfer

to the slave mode controller

/1, /2, /4, /8

(from slave mode

write_in_progress
