Basic timers (TIM6&TIM7)
17.4.4
TIM6&TIM7 status register (TIMx_SR)
Address offset: 0x10
Reset value: 0x0000
15
14
13
Bits 15:1 Reserved, must be kept at reset value.
Bit 0 UIF: Update interrupt flag
17.4.5
TIM6&TIM7 event generation register (TIMx_EGR)
Address offset: 0x14
Reset value: 0x0000
15
14
13
Bits 15:1 Reserved, must be kept at reset value.
Bit 0 UG: Update generation
This bit can be set by software, it is automatically cleared by hardware.
0: No action.
1: Re-initializes the timer counter and generates an update of the registers. Note that the
prescaler counter is cleared too (but the prescaler ratio is not affected).
17.4.6
TIM6&TIM7 counter (TIMx_CNT)
Address offset: 0x24
Reset value: 0x0000
15
14
13
rw
rw
rw
Bits 15:0
CNT[15:0]: Counter value
533/1422
12
11
10
9
This bit is set by hardware on an update event. It is cleared by software.
0: No update occurred.
1: Update interrupt pending. This bit is set by hardware when the registers are updated:
–At overflow or underflow and if UDIS = 0 in the TIMx_CR1 register.
–When CNT is reinitialized by software using the UG bit in the TIMx_EGR register, if
URS = 0 and UDIS = 0 in the TIMx_CR1 register.
12
11
10
9
12
11
10
9
rw
rw
rw
rw
Doc ID 018909 Rev 4
8
7
6
Reserved
8
7
6
Reserved
8
7
6
CNT[15:0]
rw
rw
rw
5
4
3
2
5
4
3
2
5
4
3
2
rw
rw
rw
rw
RM0090
1
0
UIF
rc_w0
1
0
UG
w
1
0
rw
rw
