Reset and clock control for (RCC)
6.3.23
RCC APB1 peripheral clock enable in low power mode register
for STM32F405xx/07xx and STM32F415xx/17xx
(RCC_APB1LPENR)
Address offset: 0x60
Reset value: 0x36FE C9FF
Access: no wait state, word, half-word and byte access.
31
30
29
DAC
PWR
LPEN
LPEN
Reserved
rw
15
14
13
SPI3
SPI2
LPEN
LPEN
Reserved
rw
rw
Bits 31:30 Reserved, must be kept at reset value.
Bit 29 DACLPEN: DAC interface clock enable during Sleep mode
Set and cleared by software.
0: DAC interface clock disabled during Sleep mode
1: DAC interface clock enabled during Sleep mode
Bit 28 PWRLPEN: Power interface clock enable during Sleep mode
Set and cleared by software.
0: Power interface clock disabled during Sleep mode
1: Power interface clock enabled during Sleep mode
Bit 27 Reserved, must be kept at reset value.
Bit 26 CAN2LPEN: CAN 2 clock enable during Sleep mode
Set and cleared by software.
0: CAN 2 clock disabled during sleep mode
1: CAN 2 clock enabled during sleep mode
Bit 25 CAN1LPEN: CAN 1 clock enable during Sleep mode
Set and cleared by software.
0: CAN 1 clock disabled during Sleep mode
1: CAN 1 clock enabled during Sleep mode
Bit 24 Reserved, must be kept at reset value.
Bit 23 I2C3LPEN: I2C3 clock enable during Sleep mode
Set and cleared by software.
0: I2C3 clock disabled during Sleep mode
1: I2C3 clock enabled during Sleep mode
Bit 22 I2C2LPEN: I2C2 clock enable during Sleep mode
Set and cleared by software.
0: I2C2 clock disabled during Sleep mode
1: I2C2 clock enabled during Sleep mode
165/1422
28
27
26
25
CAN2
CAN1
RESER
VED
LPEN
LPEN
rw
rw
rw
12
11
10
9
WWDG
LPEN
Reserved
rw
Doc ID 018909 Rev 4
24
23
22
21
I2C3
I2C2
I2C1
Reser-
LPEN
LPEN
LPEN
ved
rw
rw
rw
8
7
6
5
TIM14
TIM13
TIM12
TIM7
LPEN
LPEN
LPEN
LPEN
rw
rw
rw
rw
20
19
18
UART5
UART4
USART3
USART2
LPEN
LPEN
LPEN
LPEN
rw
rw
rw
4
3
2
TIM6
TIM5
TIM4
TIM3
LPEN
LPEN
LPEN
LPEN
rw
rw
rw
RM0090
17
16
Reser-
ved
rw
1
0
TIM2
LPEN
rw
rw
