RM0090
28.5.8 R6
Only for SD I/O. The normal response to CMD3 by a memory device. It is shown in
Table 157.

Table 157. R6 response

47
46
[45:40]
[39:8] Argument
field
[7:1]
0
The card [23:8] status bits are changed when CMD3 is sent to an I/O-only card. In this case,
the 16 bits of response are the SD I/O-only values:
●
Bit [15] COM_CRC_ERROR
●
Bit [14] ILLEGAL_COMMAND
●
Bit [13] ERROR
● Bits [12:0] Reserved
28.6

SDIO I/O card-specific operations

The following features are SD I/O-specific operations:
●
SDIO read wait operation by SDIO_D2 signalling
● SDIO read wait operation by stopping the clock
●
SDIO suspend/resume operation (write and read suspend)
● SDIO interrupts
The SDIO supports these operations only if the SDIO_DCTRL[11] bit is set, except for read
suspend that does not need specific hardware implementation.
28.6.1

SDIO I/O read wait operation by SDIO_D2 signalling

It is possible to start the readwait interval before the first block is received: when the data
path is enabled (SDIO_DCTRL[0] bit set), the SDIO-specific operation is enabled
(SDIO_DCTRL[11] bit set), read wait starts (SDI0_DCTRL[10] =0 and SDI_DCTRL[8] =1)
and data direction is from card to SDIO (SDIO_DCTRL[1] = 1), the DPSM directly moves
from Idle to Readwait. In Readwait the DPSM drives SDIO_D2 to 0 after 2 SDIO_CK clock
cycles. In this state, when you set the RWSTOP bit (SDIO_DCTRL[9]), the DPSM remains
in Wait for two more SDIO_CK clock cycles to drive SDIO_D2 to 1 for one clock cycle (in
accordance with SDIO specification). The DPSM then starts waiting again until it receives
data from the card. The DPSM will not start a readwait interval while receiving a block even
if read wait start is set: the readwait interval will start after the CRC is received. The
RWSTOP bit has to be cleared to start a new read wait operation. During the readwait
interval, the SDIO can detect SDIO interrupts on SDIO_D1.
Bit position Width (bits)
1
1
6
[31:16] 16
[15:0] 16
7
1
Doc ID 018909 Rev 4
Secure digital input/output interface (SDIO)
Value
0 Start bit
0 Transmission bit
'101000' CMD40
X RCA [31:16] of winning card or of the host
X Not defined. May be used for IRQ data
X CRC7
1 End bit
Description
884/1422
