RM0090
6.3.17
RCC APB2 peripheral clock enable register (RCC_APB2ENR)
for STM32F405xx/07xx and STM32F415xx/17xx
Address offset: 0x44
Reset value: 0x0000 0000
Access: no wait state, word, half-word and byte access.
31
30
29
15
14
13
SPI1
SYSCF
Reser-
Reser-
G EN
ved
ved
rw
Bits 31:19 Reserved, must be kept at reset value.
Bit 18 TIM11EN: TIM11 clock enable
Bit 17 TIM10EN: TIM10 clock enable
Bit 16 TIM9EN: TIM9 clock enable
Bit 15 Reserved, must be kept at reset value.
Bit 14 SYSCFGEN: System configuration controller clock enable
Bit 13 Reserved, must be kept at reset value.
Bit 12 SPI1EN: SPI1 clock enable
Bit 11 SDIOEN: SDIO clock enable
Bit 10 ADC3EN: ADC3 clock enable
28
27
26
25
Reserved
12
11
10
9
SDIO
ADC3
ADC2
EN
EN
EN
EN
rw
rw
rw
rw
Set and cleared by software.
0: TIM11 clock disabled
1: TIM11 clock enabled
Set and cleared by software.
0: TIM10 clock disabled
1: TIM10 clock enabled
Set and cleared by software.
0: TIM9 clock disabled
1: TIM9 clock enabled
Set and cleared by software.
0: System configuration controller clock disabled
1: System configuration controller clock enabled
Set and cleared by software.
0: SPI1 clock disabled
1: SPI1 clock enabled
Set and cleared by software.
0: SDIO module clock disabled
1: SDIO module clock enabled
Set and cleared by software.
0: ADC3 clock disabled
1: ADC3 clock disabled
Doc ID 018909 Rev 4
Reset and clock control for (RCC)
24
23
22
21
8
7
6
5
ADC1
USART6
EN
EN
Reserved
rw
rw
20
19
18
TIM11
TIM10
EN
rw
4
3
2
USART1
TIM8
EN
Reserved
rw
17
16
TIM9
EN
EN
rw
rw
1
0
TIM1
EN
EN
rw
rw
154/1422
