Advanced-control timers (TIM1&TIM8)
The following figures show some examples of the counter behavior for different clock
frequencies when TIMx_ARR=0x36.

Figure 80. Counter timing diagram, internal clock divided by 1

Figure 81. Counter timing diagram, internal clock divided by 2

Figure 82. Counter timing diagram, internal clock divided by 4

361/1422
CK_PSC
CNT_EN
Timer clock = CK_CNT
Counter register
Counter underflow (cnt_udf)
Update event (UEV)
Update interrupt flag (UIF)
CK_PSC
CNT_EN
Timer clock = CK_CNT
Counter register
Counter underflow
Update event (UEV)
Update interrupt flag (UIF)
CK_PSC
CNT_EN
Timer clock = CK_CNT
Counter register
Counter underflow
Update event (UEV)
Update interrupt flag (UIF)
Doc ID 018909 Rev 4
05 04 03 02 01 00 36 35 34 33 32 31 30 2F
0002
0001 0000 0036 0035 0034 0033
0001
0000
RM0090
0036 0035
