Table 12. Description Of The Option Bytes (Stm32F42Xxx And Stm32F43Xxx) - ST STM32F40 Series Reference Manual

RM0090
Table 12.
RDP: Read protection option byte.
The read protection is used to protect the software code stored in Flash memory.
Bit 15:8
USER: User option byte
This byte is used to configure the following features:
Select the watchdog event: Hardware or software
Reset event when entering the Stop mode
Reset event when entering the Standby mode
Bit 7
Bit 6
Bit 5
Bit 4
Bits 3:2
Bits 1:0
Bit 15:12
nWRP: Flash memory write protection option bytes.
Sectors 0 to 11 can be write protected.
Bits 11:0
Bit 15:0
Description of the option bytes (STM32F42xxx and STM32F43xxx)
Option bytes (word, address 0x1FFF C000)
0xAA: Level 0, no protection
0xCC: Level 2, chip protection (debug and boot from RAM features disabled)
Others: Level 1, read protection of memories (debug features limited)
nRST_STDBY
0: Reset generated when entering the Standby mode
1: No reset generated
nRST_STOP
0: Reset generated when entering the Stop mode
1: No reset generated
WDG_SW
0: Hardware watchdog
1: Software watchdog
0x1: Not used
BOR_LEV: BOR reset Level
These bits contain the supply level threshold that activates/releases the reset.
They can be written to program a new BOR level value into Flash memory.
00: BOR Level 3 (VBOR3). reset threshold level from 2.70 to 3.60 V
01: BOR Level 2 (VBOR2). reset threshold level from 2.40 to 2.70 V
10: BOR Level 1 (VBOR1). reset threshold level from 2.10 to 2.40 V
11: BOR off (VBOR0), reset threshold level from 1.8 to 2.10 V
0x1: Not used
Option bytes (word, address 0x1FFF C008)
0xF: not used
nWRPi:
0: Write protection active on selected sector
1: Write protection not active on selected sector
Option bytes (word, address 0x1FFE C000)
0xFF: not used
