PIM-SM INTERFACE STATUS
VlanId
---------
8
16
17
20
30
31
32
33
Table 20‐7 provides an explanation of the command output.
Table 20-7 show ip pimsm Output Details
Output Field
Admin Mode
Join/Prune Interval
(secs)
VlanId
Interface Mode
Protocol State

show ip pimsm componenttable

This command displays the table containing objects specific to a PIM domain. One row exists for
each domain to which the router is connected.
Syntax
show ip pimsm componenttable
Parameters
None.
Defaults
None.
Mode
Any router mode.
Example
This example shows how to display PIM router information:
C3(su)->router> show ip pimsm componenttable
Interface Mode Protocol State
-------------- ----------------
Disable Non-Operational
Enable Operational
Enable Operational
Enable Operational
Enable Operational
Disable Non-Operational
Disable Non-Operational
Disable Non-Operational
What it displays
This field indicates whether PIM-SM is enabled or disabled. This is a configured
value.
This field shows the interval at which periodic PIM-SM Join/Prune messages are to
be sent.
VLAN id associated with the PIM IP Interface.
This field indicates whether PIM-SM is enabled or disabled on the interface. This is a
configured value.
This field indicates the current state of the PIM-SM protocol on the interface.
Possible values are Operational or Non-Operational.
show ip pimsm componenttable
SecureStack C3 Configuration Guide 20-53
