1 - Start operational code.
2 - Start Boot Menu.
Select (1, 2):2
Password: *************
2. Before the boot up completes, type 2 to select "Start Boot Menu". Use "administrator" for
the Password.
Note: The "Boot Menu" password "administrator" can be changed using boot menu option 11.
Boot Menu Version 01.00.29 05-09-2005
Options available
1 - Start operational code
2 - Change baud rate
3 - Retrieve event log using XMODEM (64KB).
4 - Load new operational code using XMODEM
5 - Display operational code vital product data
6 - Run Flash Diagnostics
7 - Update Boot Code
8 - Delete operational code
9 - Reset the system
10 - Restore Configuration to factory defaults (delete config files)
11 - Set new Boot Code password
[Boot Menu] 2
3. Type 2. The following baud rate selection screen displays:
1 - 1200
2 - 2400
3 - 4800
4 - 9600
5 - 19200
6 - 38400
7 - 57600
8 - 115200
0 - no change
4. Type 8 to set the switch baud rate to 115200. The following message displays:
Setting baud rate to 115200, you must change your terminal baud rate.
5. Set the terminal baud rate to 115200 and press ENTER.
6. From the boot menu options screen, type 4 to load new operational code using XMODEM.
When the XMODEM transfer is complete, the following message and header information will
display:
[Boot Menu] 4
Ready to receive the file with XMODEM/CRC....
Ready to RECEIVE File xcode.bin in binary mode
Send several Control-X characters to cCKCKCKCKCKCKCK
XMODEM transfer complete, checking CRC....
Verified operational code CRC.
Downloading a Firmware Image
