Creating a Virtual Switch Configuration
To create a virtual switch configuration in a stack environment:
1. Display the types of switches supported in the stack, using the show switch switchtype
command (page 2‐7).
2. Using the output of the show switch switchtype command, determine the switch index (SID)
of the model of switch being configured.
3. Add the virtual switch to the stack using the set switch member command (page 2‐11). Use
the SID of the switch model, determined in the previous step, and the unit ID that you want to
assign to this switch member.
4. Proceed to configure the ports of the virtual switch as you would do for physically present
devices.
The following example adds a C3G124‐24 mode to a stack as unit 2 of the stack. The first port on
that virtual switch is then associated with VLAN 555.
C3(su)->show switch switchtype
SID
--- -------------------------------- ---- ---------
1 C2G124-24
2 C2K122-24
3 C2G124-48
4 C2G124-48P
5 C2H124-48
6 C2H124-48P
7 C2G134-24P
8 C2G170-24
9 C3G124-24P
10 C3G124-48P
11 C3G124-48
12 C3G124-24
13 C3K172-24
15 C3K122-24
17 C3K122-24P
C3(su)->set switch member 2 12
C3(su)->show switch
Switch
------ ------------ ------------- ------------- --------------------- --------
1
2
C3(su)->set vlan create 555
C3(su)->clear vlan egress 1 ge.2.1
C3(su)->set port vlan ge.2.1 555 untagged
C3(su)->show port vlan ge.2.1
ge.2.1 is set to 555
2-4 Configuring Switches in a Stack
Switch Model ID
Management Preconfig
Status Model ID
Mgmt Switch C3G124-48
Unassigned C3G124-24
Note: If you preconfigure a virtual switch and then add a physical switch of a different type to the
stack as that unit number, any configured functionality that cannot be supported on the physical
switch will cause a configuration mismatch status for that device and the ports of the new device will
join detached. You must clear the mismatch before the new device will properly join the stack.
Mgmt Code
Pref Version
1 0xa08245
1 0xa08245
1 0xa08245
1 0xa08245
1 0xa08245
1 0xa08245
1 0xa08245
1 0xa08245
1 0xa08245
1 0xa08245
1 0xa08245
1 0xa08245
1 0xa08245
1 0xa08245
1 0xa08245
Plugged-in
Model ID
C3G124-48 OK
Not Present
Switch Code
Status Version
6.03.xx.xxxx
00.00.00
