Summary of Contents for Enterasys SecureStack C3K122-24
- Page 1 Enterasys SecureStack ® Gigabit Ethernet Switch Hardware Installation Guide C3K122-24 C3K122-24P C3K172-24 C3K-2XFP P/N 9034396-01 ™...
- Page 3 Elektrischer Gefahrenhinweis: Installationen sollten nur durch ausgebildetes und qualifiziertes Personal vorgenommen werden. Enterasys Networks reserves the right to make changes in specifications and other information contained in this document and its web site without prior notice. The reader should in all cases consult Enterasys Networks to determine whether any such changes have been made. The hardware, firmware, or software described in this document is subject to change without notice. IN NO EVENT SHALL ENTERASYS NETWORKS BE LIABLE FOR ANY INCIDENTAL, INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING BUT NOT LIMITED TO LOST PROFITS) ARISING OUT OF OR RELATED TO THIS DOCUMENT, WEB SITE, OR THE INFORMATION CONTAINED IN THEM, EVEN IF ENTERASYS NETWORKS HAS BEEN ADVISED OF, KNEW OF, OR SHOULD HAVE KNOWN OF, THE POSSIBILITY OF SUCH DAMAGES. Enterasys Networks, Inc. 50 Minuteman Road Andover, MA 01810 © 2008 Enterasys Networks, Inc. All rights reserved. Part Number: 9034396‐01 September 2008 ENTERASYS, ENTERASYS NETWORKS, ENTERASYS SECURE NETWORKS, NETSIGHT, ENTERASYS NETSIGHT, SECURESTACK, ENTERASYS SECURESTACK, and any logos associated therewith, are trademarks or registered trademarks of Enterasys Networks, Inc., in the United States and/or other countries. For a complete list of Enterasys trademarks, see http://www.enterasys.com/company/trademarks.aspx. All other product names mentioned in this manual may be trademarks or registered trademarks of their respective companies. Documentation URL: http://www.enterasys.com/support/manuals Documentacion URL: http://www.enterasys.com/support/manuals...
-
Page 4: Regulatory Compliance Information
Regulatory Compliance Information Federal Communications Commission (FCC) Notice This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment uses, generates, and can radiate radio frequency energy and if not installed in accordance with the operator’s manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause interference in which case the user will be required to correct the interference at his own expense. WARNING: Changes or modifications made to this device which are not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Industry Canada Notice This digital apparatus does not exceed the class A limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications. Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la class A prescrites dans le Règlement sur le brouillage radioélectrique édicté par le ministère des Communications du Canada. Class A ITE Notice WARNING: This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Clase A. Aviso de ITE ADVERTENCIA: Este es un producto de Clase A. En un ambiente doméstico este producto puede causar interferencia de radio ... -
Page 5: Hazardous Substances
This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. This product complies with the requirements of European Directive, 2002/95/EC, Restriction of Hazardous Substances (RoHS) in Electrical and Electronic Equipment. European Waste Electrical and Electronic Equipment (WEEE) Notice In accordance with Directive 2002/96/EC of the European Parliament on waste electrical and electronic equipment (WEEE): The symbol above indicates that separate collection of electrical and electronic equipment is required and that this product was placed on the European market after August 13, 2005, the date of enforcement for Directive 2002/96/EC. When this product has reached the end of its serviceable life, it cannot be disposed of as unsorted municipal waste. It must be collected and treated separately. It has been determined by the European Parliament that there are potential negative effects on the environment and human health as a result of the presence of hazardous substances in electrical and electronic equipment. It is the users’ responsibility to utilize the available collection system to ensure WEEE is properly treated. For information about the available collection system, please go to www.enterasys.com/services/support/ Enterasys Customer Support at 353 61 705586 (Ireland). BSMI EMC Statement — Taiwan AS/NZS CISPR 22 Hazardous Substances or contact ... - Page 6 SJ/T 11363-2006 standard. This table shows where these substances may be found in the supply chain of Enterasys’ electronic information products, as of the date of sale of the enclosed product. Note that some of the component types listed above may or may not be a part of the enclosed product.
-
Page 7: Safety Information
The single mode interface modules use Class 1 laser transceivers. Read the following safety information before installing or operating these modules. The Class 1 laser transceivers use an optical feedback loop to maintain Class 1 operation limits. This control loop eliminates the need for maintenance checks or adjustments. The output is factory set, and does not allow any user adjustment. Class 1 Laser transceivers comply with the following safety standards: • 21 CFR 1040.10 and 1040.11 U.S. Department of Health and Human Services (FDA). • IEC Publication 825 (International Electrotechnical Commission). • CENELEC EN 60825 (European Committee for Electrotechnical Standardization). When operating within their performance limitations, laser transceiver output meets the Class 1 accessible emission limit of all three standards. Class 1 levels of laser radiation are not considered hazardous. When the connector is in place, all laser radiation remains within the fiber. The maximum amount of radiant power exiting the fiber (under normal conditions) is ‐12.6 dBm or 55 x 10 Removing the optical connector from the transceiver allows laser radiation to emit directly from the optical port. The maximum radiance from the optical port (under worst case conditions) is 0.8 W cm Do not use optical instruments to view the laser output. The use of optical instruments to view laser output increases eye hazard. When viewing the output optical port, power must be removed from the network adapter. Warning: Fiber Optic Port Safety When using a fiber optic media expansion module, never look at the transmit laser ... -
Page 8: Declaration Of Conformity
Application of Council Directive(s): 2004/108/EC Manufacturer’s Name: Enterasys Networks, Inc. Manufacturer’s Address: 50 Minuteman Road European Representative Name: Enterasys Networks, Ltd. European Representative Address: Nexus House, Newbury Business Park Conformance to Directive(s)/Product Standards: EC Directive 2004/108/EC Equipment Type/Environment: Information Technology Equipment, for use in a Commercial Enterasys Networks, Inc. declares that the equipment packaged with this notice conforms to the above directives. viii Declaration of Conformity 2006/95/EC Andover, MA 01810 London Road, Newbury Berkshire RG14 2PZ, England EN 55022:2006 EN 55024:1998 EN 61000‐3‐2:2000 EN 61000‐3‐3:1995 EC Directive 2006/95/EC EN 60950‐1:2001 EN 60825‐1:1994 EN 60825‐2:2004 or Light Industrial Environment. - Page 9 ENTERASYS NETWORKS, INC. FIRMWARE LICENSE AGREEMENT BEFORE OPENING OR UTILIZING THE ENCLOSED PRODUCT, CAREFULLY READ THIS LICENSE AGREEMENT. This document is an agreement (“Agreement”) between the end user (“You”) and Enterasys Networks, Inc., on behalf of itself and its Affiliates (as hereinafter defined) (“Enterasys”) that sets forth Your rights and obligations with respect to the Enterasys software program/firmware (including any accompanying documentation, hardware or media) (“Program”) in the package and prevails over any additional, conflicting or inconsistent terms and conditions appearing on any purchase order or other document submitted by You. “Affiliate” means any person, partnership, corporation, limited liability company, other form of enterprise that directly or indirectly through one or more intermediaries, controls, or is controlled by, or is under common control with the party specified. This Agreement constitutes the entire understanding between the parties, with respect to the subject matter of this Agreement. The Program may be contained in firmware, chips or other media. BY INSTALLING OR OTHERWISE USING THE PROGRAM, YOU REPRESENT THAT YOU ARE AUTHORIZED TO ACCEPT THESE TERMS ON BEHALF OF THE END USER (IF THE END USER IS AN ENTITY ON WHOSE BEHALF YOU ARE AUTHORIZED TO ACT, “YOU” AND “YOUR” SHALL BE DEEMED TO REFER TO SUCH ENTITY) AND THAT YOU AGREE THAT YOU ARE BOUND BY THE TERMS OF THIS AGREEMENT, WHICH INCLUDES, AMONG OTHER PROVISIONS, THE LICENSE, THE DISCLAIMER OF WARRANTY AND THE LIMITATION OF LIABILITY. IF YOU DO NOT AGREE TO THE TERMS OF THIS AGREEMENT OR ARE NOT AUTHORIZED TO ENTER INTO THIS AGREEMENT, ENTERASYS IS UNWILLING TO LICENSE THE PROGRAM TO YOU AND YOU AGREE TO RETURN THE UNOPENED PRODUCT TO ENTERASYS OR YOUR DEALER, IF ANY, WITHIN TEN (10) DAYS FOLLOWING THE DATE OF RECEIPT FOR A FULL REFUND. IF YOU HAVE ANY QUESTIONS ABOUT THIS AGREEMENT, CONTACT ENTERASYS NETWORKS, LEGAL DEPARTMENT AT (978) 684‐1000. You and Enterasys agree as follows: LICENSE. You have the non‐exclusive and non‐transferable right to use only the one (1) copy of the Program provided in ...
- Page 10 THE CUMULATIVE LIABILITY OF ENTERASYS TO YOU FOR ALL CLAIMS RELATING TO THE PROGRAM, IN CONTRACT, TORT OR OTHERWISE, SHALL NOT EXCEED THE TOTAL AMOUNT OF FEES PAID TO ENTERASYS BY YOU FOR THE RIGHTS GRANTED HEREIN. AUDIT RIGHTS. You hereby acknowledge that the intellectual property rights associated with the Program are of critical value to Enterasys, and, accordingly, You hereby agree to maintain complete books, records and accounts showing (i) license fees due and paid, and (ii) the use, copying and deployment of the Program. You also grant to Enterasys and its authorized representatives, upon reasonable notice, the right to audit and examine during Your normal business hours, Your books, records, accounts and hardware devices upon which the Program may be deployed to verify compliance with this Agreement, including the verification of the license fees due and paid Enterasys and the use, copying and deployment of the Program. Enterasys’ right of examination shall be exercised reasonably, in good faith and in a manner calculated to not unreasonably interfere with Your business. In the event such audit discovers non‐compliance with this Agreement, including copies of the Program made, used or deployed in breach of this Agreement, You shall promptly pay to Enterasys the appropriate license fees. Enterasys reserves the right, to be exercised in its sole discretion and without prior notice, to terminate this license, effective immediately, for failure to comply with this Agreement. Upon any such termination, You shall immediately cease all use of the Program and shall return to Enterasys the Program and all copies of the Program. OWNERSHIP. This is a license agreement and not an agreement for sale. You acknowledge and agree that the Program constitutes trade secrets and/or copyrighted material of Enterasys and/or its suppliers. You agree to implement reasonable security measures to protect such trade secrets and copyrighted material. All right, title and interest in and to the Program shall remain with Enterasys and/or its suppliers. All rights not specifically granted to You shall be reserved to Enterasys. 10. ENFORCEMENT. You acknowledge and agree that any breach of Sections 2, 4, or 9 of this Agreement by You may cause Enterasys irreparable damage for which recovery of money damages would be inadequate, and that Enterasys may be entitled to seek timely injunctive relief to protect Enterasys’ rights under this Agreement in addition to any and all remedies available at law. 11. ASSIGNMENT. You may not assign, transfer or sublicense this Agreement or any of Your rights or obligations under this Agreement, except that You may assign this Agreement to any person or entity which acquires substantially all of Your stock assets. Enterasys may assign this Agreement in its sole discretion. This Agreement shall be binding upon and inure to the benefit of the parties, their legal representatives, permitted transferees, successors and assigns as permitted by this Agreement. Any attempted assignment, transfer or sublicense in violation of the terms of this Agreement shall be void and a breach of this Agreement. 12. WAIVER. A waiver by Enterasys of a breach of any of the terms and conditions of this Agreement must be in writing and will not be construed as a waiver of any subsequent breach of such term or condition. Enterasys’ failure to enforce a term upon Your breach of such term shall not be construed as a waiver of Your breach or prevent enforcement on any other occasion.
- Page 11 13. SEVERABILITY. In the event any provision of this Agreement is found to be invalid, illegal or unenforceable, the validity, legality and enforceability of any of the remaining provisions shall not in any way be affected or impaired thereby, and that provision shall be reformed, construed and enforced to the maximum extent permissible. Any such invalidity, illegality, or unenforceability in any jurisdiction shall not invalidate or render illegal or unenforceable such provision in any other jurisdiction. 14. TERMINATION. Enterasys may terminate this Agreement immediately upon Your breach of any of the terms and conditions of this Agreement. Upon any such termination, You shall immediately cease all use of the Program and shall return to Enterasys the Program and all copies of the Program.
-
Page 13: Table Of Contents
Installing the Rubber Feet ... 2-10 Guidelines for Installation on a Flat Surface ... 2-10 Mounting a C3K Switch in a 19-Inch Rack ... 2-11 Guidelines for Installation in a 19-Inch Rack ... 2-12 Attaching Brackets and Installing in Rack ... 2-12 Connecting High-Speed Stacking Cables ... - Page 14 About SecureStack C3K Switch Operation in a Stack ... 2-15 Recommended Procedures for New and Existing Stacks ... 2-16 Installing a New Stackable System of Up to Eight Switches ... 2-16 Adding a New Switch to an Existing Stack ...2-17 Connect AC and RPS Power ...
-
Page 15: About This Guide
Depending on the firmware version used in your C3K switch, some features described in this document may not be supported. Refer to the Release Notes shipped with the switch to determine which features are supported. Who Should Use This Guide This guide is intended for a network administrator responsible for installing and setting up the ... -
Page 16: Related Documents
Related Documents Related Documents The documents listed below provide the necessary information to install and configure the switch and can be obtained from the World Wide Web in Adobe Acrobat Portable Document Format (PDF) at the following site: http://www.enterasys.com/support/manuals • SecureStack C3 Configuration Guide describes how to use the Command Line Interface (CLI) to set up and manage the C3K switch. • SecureStack C2 Redundant Power System C2RPS‐SYS Installation Guide provides hardware specifications and instructions to install the power supply and its options. Conventions Used in This Guide The following conventions are used in this guide: Note: Calls the reader’s attention to any item of information that may be of special importance. Caution: Contains information essential to avoid damage to the equipment. -
Page 17: Commonly Used Acronyms
• Network load and frame size at the time of trouble (if known) www.enterasys.com/services/support/ 1-800-872-8440 (toll-free in U.S. and Canada) or 1-978-684-1000 For the Enterasys Networks Support toll-free number in your country: www.enterasys.com/services/support/contact/ support@enterasys.com To expedite your message, please type [SWITCHING] in the subject line. SecureStack C3K Hardware Installation Guide xvii... - Page 18 Getting Help • The device history (for example, if you have returned the device before, or if this is a recurring problem) • Any previous Return Material Authorization (RMA) numbers xviii About This Guide...
-
Page 19: Chapter 1: Introduction
Depending on the firmware version used in the switch, some features described in this document may not be supported. Refer to the Release Notes shipped with your C3K switch features are supported. For information about... C3K Hardware Overview PoE (Power over Ethernet) Support... -
Page 20: C3K122-24 And C3K122-24P
Note: Each of these Mini-GBIC ports eliminates the availability of one RJ45 port on a C3K122-24 or C3K122-24P switch. For example, when a Mini-GBIC installed in one of the Combo SFP ports (21 through 24) establishes a link, the associated fixed front panel RJ45 10BASE-T/100BASE-TX/1000BASE-T port is disabled. -
Page 21: C3K172-24
(SFP) Mini‐GBICs for 1000BASE‐FX and 100BASE‐FX fiber‐optic connections and 1000BASE‐T copper connections. • Rear panel connectors for high‐speed connections in a stack configuration. • Rear panel Redundant Power Supply connector for a redundant power supply connection. The switch connects to an Enterasys C2RPS‐SYS using a C2RPS‐PSM Cable. • Slot for the optional C3K‐2XFP Input/Output Module (IOM). Caution: The C3K172-24 is not a PoE-compliant device. Do not connect a SecureStack C2 PoE Redundant Power System (C2RPS-POE) to the power connector. Otherwise, damage to the device may result. Precaución: El dispositivo C3K172-24 no cumple con el estándar PoE. No conecte una fuente de poder redundante (RPS) SecureStack C2 PoE (C2RPS-POE) al cable de corriente directa. -
Page 22: C3K-2Xfp Input/Output Module
C3K Hardware Overview C3K-2XFP Input/Output Module The C3K‐2XFP (Figure that can be inserted in your C3K series switch. The C3K‐2XFP IOM is installed in C3K switches labeled with a ‐G and is an optional add‐on for all other C3K switches. The C3K‐2XFP includes: • Two XFP slots that provide you with the option of installing XFP MSA compliant modules for 10‐Gigabit, 10GBASE‐XX fiber‐optic uplink connections. Figure 1-3 Optional C3K-2XFP Input/Output Module 1 XFP port status LEDs High-Speed Stack Connections C3K switches have rear‐panel connectors for high‐speed connections in a stack configuration. The high‐speed stacking cables used for the connections are optional items and must be ordered separately. See “Connecting High‐Speed Stacking Cables” on page 2‐13 for more information about high‐speed stack connections and available cables. Redundant Power Supply Capability The switch has redundant power supply capability when connected to an optional external redundant power supply (RPS). If the internal power supply fails, the RPS assumes the entire load of the switch without interrupting network traffic. The internal power supply and RPS each have their own AC power connection, which enables the connection of each power supply to a different ... -
Page 23: Poe (Power Over Ethernet) Support
The switch is fully compliant with the IEEE 802.3af standard. It supports the standard resistor‐ based detection method, as well as AC disconnect capability. The switch is also capable of supplying 15.4 watts of power to all ports simultaneously. Powered Device Classifications PDs are devices that receive their operating 48 Vdc power through a new or existing Ethernet cable from a switch or other device that can provide a PoE‐compliant port connection. This enables the PD to operate in a location without local power. For example: • Devices such as PoE‐compliant remote EXIT signs and Personal Data Assistants (PDAs), • Devices that support Voice over IP such as PoE‐compliant digital telephones, • Devices that support Wireless Application Protocol (WAP) such as security cameras, laptop PCs, and many more devices. Management Management of the switch can be either in‐band or out‐of‐band. In‐band remote management is possible using Telnet, Enterasys Networks NetSight application. Out‐of‐band management is provided through the DB9 console port on the front panel using a VT100 terminal or a VT100 terminal emulator. Switch Configuration Using WebView Enterasys Networks HTTP‐based Web management application (WebView) is an intuitive web tool for simple management tasks. PoE (Power over Ethernet) Support ® management application, or the WebView SecureStack C3K Hardware Installation Guide 1-5... -
Page 24: Switch Configuration Using Cli Commands
Standards Compatibility Switch Configuration Using CLI Commands The CLI commands enable you to perform more complete switch configuration management tasks. For CLI command set information and how to configure the module, refer to the SecureStack C3 Configuration Guide. Standards Compatibility The 1000BASE‐T ports are compliant with the following standards and operations: • IEEE 802.3 • IEEE 802.3u • IEEE 802.3ab • Full‐Duplex operation • IEEE 802.3x Flow Control support Full‐Duplex mode The SFP ports are compliant with the following standards and operations: • IEEE 802.3z • IEEE 802.3x Flow Control support for Full‐Duplex mode • Auto‐negotiation for Full‐Duplex control operation The XFP ports are compliant with the following standards and operations: • IEEE 802.3ae 10GbE The stacking port provides 48 Gbps per port connected to Member switches for up and down link connections. LANVIEW Diagnostic LEDs LANVIEW diagnostic LEDs serve as an important troubleshooting aid by providing an easy way to observe the status of individual ports and overall network operations. -
Page 25: Hardware Installation
Read the Release Notes shipped with the switch to check for any exceptions to the supported features and operation documented in this guide. Electrical Hazard: Only qualified personnel should perform installation procedures. Riesgo Electrico: Solamente personal calificado debe realizar procedimientos de instalacion. -
Page 26: Installation Prerequisites
Rubber feet with adhesive backing for installation on a flat surface AC power cord (The type of power cord is country dependent.) DB9 female-to-DB9 female management console cable Customer Release Notes URL notice card Quick Reference Guide Remove the tape seal on the non‐conductive bag to remove the switch. Perform a visual inspection of the switch for any signs of physical damage. Contact Enterasys Networks if there are any signs of damage. See “Getting Help” on page xvii for more information on contacting Enterasys Networks. 2-2 Hardware Installation 2‐1. Quantity... -
Page 27: Installing The C3K-2Xfp Input/Output Module
Installing the C3K-2XFP Input/Output Module This section details the steps to prepare, install, and remove the optional C3K‐2XFP input/output module (IOM). Note: Enterasys Networks recommends that you install any options before connecting power to the switch. Unpacking the C3K-2XFP IOM Unpack the C3K‐2XFP as follows: Open the carton and remove the packing material protecting the C3K‐2XFP. Verify the carton contents with the items listed in Table Table 2-2 Contents of Switch Carton Item C3K-2XFP IOM Quick Reference Guide Before removing the IOM from the antistatic packaging, it is recommended that you use an ... -
Page 28: Removing The C3K-2Xfp From The C3K Switch
Installing the C3K-2XFP Input/Output Module Figure 2-1 Install the C3K-2XFP IOM 1 Guide rails Removing the C3K-2XFP from the C3K Switch This section describes how to remove your C3K‐2XFP from your C3K switch. Your C3K switch must be powered off before removing the C3K‐2XFP IOM. To remove the C3K‐2XFP IOM from your C3K switch: Power off your C3K switch. Disconnect cabling and XFPs from the module. Loosen the two captive screws on the front of the C3K‐2XFP IOM. Using the C3K‐2XFP’s handle, gently remove the C3K‐2XFP IOM from your C3K switch. If storing your C3K‐2XFP IOM, insert the C3K‐2XFP into antistatic packaging. Return the coverplate to the expansion slot and tighten the captive screws. 2-4 Hardware Installation... -
Page 29: Installing Mini-Gbics
The Mini-GBIC and switch are sensitive to static discharges. Use an antistatic wrist strap and observe all static precautions during this procedure. Failure to do so could result in damage to the Mini-GBIC and switch. Always leave the Mini-GBIC in the antistatic bag or an equivalent antistatic container when not installed. - Page 30 Installing Mini-GBICs Figure 2-2 Mini-GBIC with Non-LC Connector 1 Port slot 2 Release tab 3 Mini-GBIC (MGBIC-MT01 shown) Figure 2-3 Mini-GBIC with LC Connector 1 Port slot 2 Release tab 3 7-pin edge connector (insertion side) 2-6 Hardware Installation 4 Protective dust cover 5 7-pin edge connector (insertion side) 6 Mini-GBIC top side...
-
Page 31: Removing A Mini-Gbic
Removing a Mini-GBIC Caution: Do NOT remove a Mini-GBIC from a slot without releasing the locking tab located at the front of the Mini-GBIC. This can damage the Mini-GBIC. The Mini-GBIC and its host device are sensitive to static discharges. Use an antistatic wrist strap and observe all static precautions during this procedure. -
Page 32: Installing An Xfp
The XFP and switch are sensitive to static discharges. Use an antistatic wrist strap and observe all static precautions during this procedure. Failure to do so could result in damage to the XFP and switch. Always leave the XFP in the antistatic bag or an equivalent antistatic container when not installed. -
Page 33: Removing An Xfp
Attempting to remove the XFP without releasing it can damage the XFP. The XFP and its host switch are sensitive to static discharges. Use an antistatic wrist strap and observe all static precautions during this procedure. Failure to do so could result in damaging the XFP or host switch. -
Page 34: Installing The Rubber Feet
5.1 cm (2 pulgadas) con respecto a los lados y a la parte posterior del aparato. Note: Do not connect the switch to the AC power source until instructed to do so later in the installation process. -
Page 35: Mounting A C3K Switch In A 19-Inch Rack
Area Guidelines for Switch Installation on Flat Surface 1 Approximately 152 cm (5 ft) from power source 2 4.45 cm (1.75 in.) per switch. (Vertical clearance depends on number of switches stacked.) Mounting a C3K Switch in a 19-Inch Rack To install the C3K switch in a 19‐inch rack, you need: ... -
Page 36: Guidelines For Installation In A 19-Inch Rack
Note: To ensure proper ventilation and prevent overheating, leave a minimum clearance space of 5.1 cm (2.0 in.) at the left, right, and rear of the switch. Warning: Before rack-mounting the device, ensure that the rack can support it without compromising stability. -
Page 37: Connecting High-Speed Stacking Cables
With the mounting brackets attached, position the switch between the vertical frame members of the 19‐inch rack as shown in Figure frame using four mounting screws (user supplied). Figure 2-7 Fastening the Switch to the Rack 1 Rails of 19-inch rack If you are installing this switch in a stacked configuration, repeat this procedure for each switch until all switches have been installed in the stack, then proceed to “Connecting High‐ Speed Stacking Cables” on page 2‐13. Otherwise, proceed to “Connect AC and RPS Power” on page 2‐17. Connecting High-Speed Stacking Cables The stack of switches can be connected in a ring or daisy chain topology. In a ring topology all the switches are connected. The only difference in the cable connections in a daisy chain topology is that one cable is not installed. Up to 8 switches can be stacked together and connected by high‐speed stacking cables. You can add switches and reach up to a maximum of 384 Ethernet ports per stack. The high‐speed stacking cables allow the entire stack to operate with a single IP address. There are four types of cables: • C2CAB‐SHORT — Cable to connect two adjacent switches in the stack (30.6 cm). Connecting High-Speed Stacking Cables 2‐7 on page 2‐13. Then fasten the switch securely to the ... - Page 38 Connecting High-Speed Stacking Cables • C2CAB‐LONG — One meter cable to connect from the top switch to the bottom switch in the stack. This cable can also be used in place of the C2CAB‐SHORT cable to connect switches that are too far apart due to the physical arrangement of the switches in the stack. • C2CAB‐2M — Two meter cable to connect from the top switch to the bottom switch in the stack when these two switches are physically located in separate mounting racks and require a longer cable to reach. • C2CAB‐5M — Five meter cable to connect from the top switch to the bottom switch in the stack when these two switches are physically located in separate mounting racks and require a longer cable to reach. Note: The high-speed stacking cables are optional items and must be ordered separately. If the stack is in a configuration where the adjacent switches are too far apart for C2CAB-SHORT cables, C2CAB-LONG cables can be used for the connections.
-
Page 39: Configuring Switches In A Stack
Configuring Switches in a Stack The information in the following sections is important to understand C3K switch operation in a stack installation. About SecureStack C3K Switch Operation in a Stack Once your C3K switches are installed in a stack, the switches behave and perform as a single switch. As such, you can start with a single switch and add more switches as your network expands. You can also mix different C Series products in a single stack to provide a combination of port types and functions to match your network requirements. In all cases, a stack of switches performs as one large product, and is managed as a single network entity. When switches are installed and connected as described back in “Connecting High‐Speed Stacking Cables” on page 2‐13, the following occurs during initialization: • The switch that will manage the stack is automatically established and is referred to as the Manager switch. • All other switches are established as Member switches in the stack. • The hierarchy of the switches that will assume the function of backup manager is also determined in case the current manager malfunctions, is powered down, or is disconnected from the stack. • The console port on the manager switch remains active for out‐of‐band (local) switch management, but the console port on each member switch is deactivated. This enables you to set the IP address and system password using a single console port. Now each switch can be configured locally using only the manager’s console port, or inband using a remote device and the CLI set of commands described in this section. For procedures used for various types of connections to the Console port, refer to “Connecting to Console Port for Local Management” on page 2‐19. -
Page 40: Recommended Procedures For New And Existing Stacks
The following procedures assume that all switches have a clean configuration from manufacturing. When adding a new switch to an already running stack, it is also assumed that the new switch is using the same firmware image version as other switches in the stack. -
Page 41: Adding A New Switch To An Existing Stack
• Use clear config to clear config parameters without clearing stack switch IDs. This command WILL NOT clear stack parameters and avoids the process of re-numbering the stack. • Use clear config all when it is necessary to clear all config parameters, including stack switch IDs and switch priority values. -
Page 42: Connecting Rps Power
Note: If the CPU LED illuminates solid red, there was a critical failure. For more information about the LED indications and troubleshooting, refer to “Troubleshooting” on page 3-1. If you need additional help, contact Enterasys Networks. Refer to on page xvii for details If the switch is a standalone switch, it will take approximately 30 seconds for the switch to ... -
Page 43: Stack Initialization Overview
Note: When switches are connected in a stack configuration and all high-speed stacking cables are connected before powering up the switches, one switch in the stack will be automatically designated as the Manager of the stack and its Console port will remain active. -
Page 44: Connecting To An Ibm Or Compatible Device
Connecting to Console Port for Local Management Figure 2-10 DB9 Male Console Port Pinout Assignments  Á À Connecting to an IBM or Compatible Device To connect an IBM PC or compatible device, running the VT terminal emulation, to an Enterasys switch Console port (Figure Connect the DB9 female connector at one end of the cable to the Console port on the C3K switch. (If there is a switch designated as the Manager, connect to its Console port.) Plug the DB9 female connector at the other end of cable into the communications port on the Turn on the PC and configure your VT emulation package with the following parameters: Parameter Mode Transmit Bits Parity Stop Bit When these parameters are set, the Startup screen will display. Proceed to “Connecting to the Network” on page 2‐23. -
Page 45: Connecting To A Vt Series Terminal
Connecting to a VT Series Terminal To connect a VT Series terminal to a C3K switch Console port (Figure interface cable terminated with a DB9 female connector and a DB25 female connector and proceed as follows: Connect the DB9 female connector at one end of cable to the Console port on the C3K switch. (If there is a switch designated as the Manager, connect to its Console port.) Plug the DB25 female connector at the other end of the cable into the port labeled COMM on the VT terminal. Turn on the terminal and access the Setup Directory. Set the following parameters on your terminal: Parameter Mode Transmit Bits Parity Stop Bit When these parameters are set, the Startup screen will display. Proceed to “Connecting to the Network” on page 2‐23. Figure 2-12 Connecting a VT Series Terminal 1 VT terminal or PC with VT emulation application... -
Page 46: Connecting To A Modem
Connecting to Console Port for Local Management Connecting to a Modem To connect a modem to a C3K switch modem port (Figure a DB9 female connector and a DB25 male connector, and proceed as follows: Connect the DB9 female connector at one end of the cable to the Console port on the C3K switch. (If there is a switch designated as the Manager, connect to its Console port.) Plug the DB25 male connector at the other end of the cable into the modem communications port. Turn on the modem and make sure the remote modem is ON. With your PC connected to the remote modem, configure your VT emulation package with the following parameters: Parameter Mode Transmit Bits Parity Stop Bit When these parameters are set, the Startup screen will display. If the switches are in a stacked configuration, proceed to “Connecting to the Network” on page 2‐23. Figure 2-13 Connecting to a Modem 1 PC with VT emulation application... -
Page 47: Connecting To The Network
Connecting to the Network The following procedures cover the cable connections from the network or other devices to the switch RJ45 ports or any installed optional SFP or XFP. • Connecting UTP Cables on page 2‐23 • Connecting Fiber‐Optic Cables to LC Ports on page 2‐26 Connecting UTP Cables The fixed RJ45 front panel ports are 10/100/1000 Mbps ports and have internal crossovers. When connecting a workstation to these ports, use a straight‐through cable. When connecting networking devices to these ports, such as a bridge, repeater, or router, use a crossover cable. Note: All fixed RJ45 front panel ports support Category 5 Unshielded Twisted Pair (UTP) cabling with an impedance between 85 and 111 ohms. Category 3 cable may be used if the connection is going to be used only for 10 Mbps. - Page 48 Verify that the RJ45 connectors on the twisted pair segment have the proper pinouts and check the cable for continuity. Typically, a crossover cable is used between hub devices. A straight‐through cable is used to connect between switches or hub devices and an end user (computer). Refer to Figure 2‐15 and Figure Refer to Figure 2‐17 and Figure d. Ensure that the twisted pair connection meets the dB loss and cable specifications outlined in the Cabling Guide. Refer to “Related Documents” on page xvi for information on obtaining this document. If a link is not established, contact Enterasys Networks. Refer to “Getting Help” on page 1‐5 for details. Repeat all steps above until all connections have been made. Figure 2-15 Four-Wire Crossover Cable RJ45 Pinouts for 10/100BASE-TX 1 RJ45 switch port 2 Other device port Figure 2-16 Four-Wire Straight-Through Cable RJ45 Pinouts for 10/100BASE-TX...
- Page 49 Figure 2-17 Eight-Wire Crossover Cable RJ45 Pinouts for 10/100/1000BASE-TX À 1 RJ45 device port 2 Other device port Figure 2-18 Eight-Wire Straight-Through Cable RJ45 Pinouts for 10/100/1000BASE-TX À 1 RJ45 device port 2 Other device port 3 RJ45-to-RJ45 straight-through cable Connecting to the Network Á...
-
Page 50: Connecting Fiber-Optic Cables To Lc Ports
Transmit (TX) • Receive (RX) The transmit strand from a device port connects to the receive port of a fiber‐optic Gigabit Ethernet device at the other end of the segment. The receive strand of the applicable LC port connects to the transmit port of the fiber‐optic Gigabit Ethernet device. Enterasys recommends labeling fiber‐optic cables to indicate receive and transmit ends. Many cables are pre‐labeled, providing matching labels or tapes at both ends of each strand of cable. To connect an LC cable connector to a fixed LC connector, refer to Figure follows: Caution: Do not touch the ends of the fiber-optic strands, and do not let the ends come in contact with dust, dirt, or other contaminants. Contamination of cable ends causes problems in data transmissions. - Page 51 1 XFP LC port connector 2 LC cable connector 3 Release tab 4 Link/Activity LED Plug the other end of the cable into the appropriate port on the other device. Some cables may be terminated at the other end with two separate connectors, one for each fiber‐optic strand. In this case, ensure that the transmit fiber‐optic strand is connected to the receive port and the receive fiber‐optic strand to the transmit port. Verify that a link exists by checking that the port Link/Activity LED is on (blinking green or solid green). If the Link/Activity LED is off, perform the following steps until it is on: Verify that the device at the other end of the segment is ON and connected to the segment. b. If there are separate fiber‐optic connections on the other device, check the crossover of the cables. Swap the cable connections if necessary. Check that the fiber‐optic connection meets the dB loss and cable specifications outlined in the Cabling Guide for multimode mode cabling. To obtain this document, refer to “Related Documents” on page xvi. d. If a link has not been established, refer to “Troubleshooting” on page 3‐1 for LED troubleshooting details. If a problem persists, refer to “Getting Help” on page xvii for details on contacting Enterasys Networks for support. Repeat steps 1 through 4, above, until all connections have been made. Connecting to the Network LC SecureStack C3K Hardware Installation Guide 2-27...
-
Page 52: Completing The Installation
Completing the Installation Completing the Installation After installing the switch and making the connections to the network, access the switch management, as described below. Initial Switch Management Logon To initially access switch management from your local PC, terminal, or modem connection, proceed as follows at the displayed startup screen: Enter admin for Username. At the Password prompt, press Enter (Return). For details on how to configure the switch using the command line interface, refer to the SecureStack C3 Configuration Guide. The CLI commands enable you to set a new password and perform more involved management configurations on the switch. One of many capabilities is to reconfigure the stack, reassigning the Manager function to another switch and configuring the order of Member switches that will take over the stack management functions in case the operating Manager is powered down, malfunctions, or is removed from the stack. After the initial configuration, you can also use WebView (Enterasys Networks’ embedded web server) for configuration and management tasks. All the guides associated with the switch are available online at: http://www.enterasys.com/support/manuals Once you are confident that the installation is successful, route and secure your cables. If you require assistance, contact Enterasys Networks using one of the methods described in “Getting Help” on page xvii. 2-28 Hardware Installation... -
Page 53: Chapter 3: Troubleshooting
This chapter provides information regarding the following: For information about... Using LANVIEW Troubleshooting Checklist Using the Password Reset Button This device contains a battery that is not considered a user replaceable part. If the battery needs to be replaced, contact customer service for repair. Caution: There is a risk of explosion if the battery is replaced with an incorrect type. Dispose of used batteries according to instructions supplied with the batteries. Precaucion: Hay riesgo de explosion si la bateria se reemplaza con el typo incorrecto. -
Page 54: Using Lanview
Using LANVIEW Using LANVIEW C3K series switches utilize the Enterasys Networks built‐in LANVIEW LED visual diagnostic and status monitoring system. The location of each LANVIEW LED is shown in Figure enable you to quickly observe network status for diagnosing switch and network problems. Figure 3-1 C3K122-24 LANVIEW LEDs 1 CPU LED 2 STACK DOWN LED 3 STACK UP LED 4 RPS LED for redundant power-source status 8 Link/Activity LEDs for XFP ports, 25 and 26 Table 3‐1 on page 3‐3 describes the LED indications and provides recommended actions as ... - Page 55 Contact Enterasys Networks for technical support. If the LED remains red for several minutes, the system may have a fatal error. Contact Enterasys Networks for technical support. If the LED remains amber for more than several minutes, contact Enterasys Networks for technical support.
- Page 56 Using LANVIEW Table 3-1 LANVIEW LEDs (continued) Color State Manager Switch is operating as a Member in the stack. Green Solid. Switch is operating as the Manager of the stack. RPS not in use. Internal power supply failure. Amber Solid. The switch internal power supply failed, and the RPS is providing the proper power to the switch.
-
Page 57: Troubleshooting Checklist
Configuration Guide for instructions to enable/disable ports. Verify that all network connections between the network management station and the device are valid and operating. If the problem continues, contact Enterasys Networks for technical support. Verify that Spanning Tree is enabled. Refer to the SecureStack C3 Configuration Guide for the instructions to set the type of STA. -
Page 58: Using The Password Reset Button
Using the Password Reset Button If you forget the switch login password, use the Password Reset button as described in the following procedure. Figure 3-2 Password Reset Button 1 Password Reset switch To reset the switch password, refer to Figure Note: Notify the system manager before changing the password. Press‐and‐hold the Reset button while the switch is operational. This change of the login password to the default password will be indicated via CLI only. Logon to device management. You can now logon to the switch via the Console port and assign a new password using the command line interface (CLI). To access switch management from your local PC, terminal, or modem connection, refer to the SecureStack C3 Configuration Guide for instructions on how to log in and enter a new password. The guide is available online at: http://www.enterasys.com/support/manuals If you require assistance, contact Enterasys Networks using one of the methods described in “Getting Help” on page xvii. 3-6 Troubleshooting 3‐2 and proceed as follows:... -
Page 59: Appendix A: Specifications
For information about... Switch Specifications C3K-2XFP Specifications 1-Gigabit Ethernet and 100Base-FX Transceiver (SFP) Specifications 10-Gigabit Ethernet Transceiver (XFP) Specifications Console Port Pinout Assignments Regulatory Compliance Enterasys Networks reserves the right to change the specifications at any time without notice. Specifications Refer to page... A-10 A-11 A-12 SecureStack C3K Hardware Installation Guide A-1... -
Page 60: Switch Specifications
Switch Specifications Switch Specifications C3K122-24 Table A‐1 provides the I/O ports, processors and memory, physical, and environmental specifications for the C3K122‐24. Table A-1 C3K122-24 Switch Specifications Item RJ45 ports 1 through 24 SFP ports 21 through 24 Physical Dimensions Approximate Weight Predicted hours for Mean Time Between Failures (MTBF) Heat Dissipation (maximum) AC Input Specifications... -
Page 61: C3K122-24P
C3K122-24P Table A‐2 provides the I/O ports, processors and memory, physical, and environmental specifications for the C3K122‐24P. Table A-2 C3K122-24P Switch Specifications Item RJ45 ports 1 through 24 SFP ports 21 through 24 Physical Dimensions Approximate Weight Predicted hours for Mean Time Between Failures (MTBF) Heat Dissipation (maximum) AC Input Specifications Input Voltage... -
Page 62: C3K172-24
Switch Specifications C3K172-24 Table A‐3 provides the I/O ports, processors and memory, physical, and environmental specifications for the C3K172‐24. Table A-3 C3K172-24 Switch Specifications Item SFP ports 1 through 24 Physical Dimensions Approximate Weight Predicted hours for Mean Time Between Failures (MTBF) Heat Dissipation (maximum) AC Input Specifications Input Voltage Input Current Frequency... -
Page 63: C3K-2Xfp Specifications
C3K-2XFP Specifications Table A‐4 provide the I/O ports, physical, and environmental specifications for the C3K‐2XFP optional IOM. Table A-4 C3K-2XFP IOM Specifications Item XFP ports Physical Dimensions Approximate Weight Predicted hours for Mean Time Between Failures (MTBF) Heat Dissipation (maximum) Environmental Operating Temperature Storage Temperature Operating Relative Humidity Specification Two XFP ports that support 10-Gigabit Ethernet connections. 170.00 x 131.15 x 33.30 mm .99 lbs (0.45 kg) 704,995... -
Page 64: 1-Gigabit Ethernet And 100Base-Fx Transceiver (Sfp) Specifications
1-Gigabit Ethernet and 100Base-FX Transceiver (SFP) Specifications 1-Gigabit Ethernet and 100Base-FX Transceiver (SFP) Specifications The C3K SFP (Mini‐GBIC) port interface slots support 1‐Gbps fiber‐optic and copper connections as described in Table Table A-5 Mini-GBIC Input/Output Port Specifications Item MGBIC-LC01 MGBIC-MT01 MGBIC-02 MGBIC-LC03 MGBIC-LC04 MGBIC-LC05 MGBIC-LC07 MGBIC-08 MGBIC-LC09 The specifications for the Mini‐GBICs shown in Table standard. MGBIC-LC01/MGBIC-MT01 Specifications (1000BASE-SX) Table A-6 MGBIC-LC01/MGBIC-MT01 Optical Specifications Item Transmit Power (minimum) Receive Sensitivity... -
Page 65: Mgbic-02 Specifications (1000Base-T
MGBIC-02 Specifications (1000BASE-T) Table A-8 MGBIC-02 Specifications Item Supported Cable Type: Maximum Length Connector Data Rate TX Output impedance RX Input impedance MGBIC-LC03 Specifications (1000BASE-SX) Table A-9 MGBIC-LC03 Optical Specifications Item Transmit Power (minimum) Transmit Power (maximum) Receive Sensitivity Link Power Budget (Multimode Only) 1. -
Page 66: Mgbic-Lc04 Specifications (100Base-Fx
1-Gigabit Ethernet and 100Base-FX Transceiver (SFP) Specifications MGBIC-LC04 Specifications (100BASE-FX) Table A-11 MGBIC-LC04 Optical Specifications Item Transmit Power (minimum) Receive Sensitivity Link Power Budget 1. The maximum drive distance (up to 2 km) depends on the quality of the installed multimode fiber-optic cable segment. -
Page 67: Mgbic-Lc07 Specifications (1000Base-Elx
MGBIC-LC07 Specifications (1000BASE-ELX) Table A-15 MGBIC-LC07 Optical Specifications Item Transmit Power (minimum) Receive Sensitivity Maximum Input Power Link Power Budget (Full Duplex Only) 1. The maximum drive distance (up to 110 km) depends on the quality of the installed single-mode fiber-optic cable segment. -
Page 68: Mgbic-Lc09 Specifications (1000Base-Lx
10-Gigabit Ethernet Transceiver (XFP) Specifications MGBIC-LC09 Specifications (1000BASE-LX) Table A-19 MGBIC-LC09 Optical Specifications Item Transmit Power (minimum) Receive Sensitivity Link Power Budget Table A-20 MGBIC-LC09 Operating Range Item 62.5 µm MMF 50 µm MMF 50 µm MMF 10 µm SMF 10-Gigabit Ethernet Transceiver (XFP) Specifications The 10‐Gigabit Small Form Factor Pluggable (XFP) interface port slots on the C3K‐2XFP module ... -
Page 69: Console Port Pinout Assignments
Table A-22 Recommended Cable Types and Specifications Item 10GBASE-LR-XFP 10GBASE-ER-XFP 10GBASE-ZR-XFP 10GBASE-SR-XFP 10GBASE-CX4-XFP CX4 TwinAxial 1. The limiting factor is saturation of the receiver by the transmitter. When presented with a signal at a strength above the saturation point, the receiver cannot distinguish between pulses, though no hardware damage occurs. -
Page 70: Regulatory Compliance
Regulatory Compliance Regulatory Compliance This product meets the safety, electromagnetic compatibility (EMC), and environmental requirements listed in Table Table A-23 Compliance Standards Regulatory Compliance Safety Electromagnetic Compatibility (EMC) Environmental A-12 Specifications A‐23: Standards UL 60950-1, FDA 21 CFR 1040.10 and 1040.11, CAN/ CSA C22.2 No. 60950-1, EN 60950-1, EN 60825-1, EN 60825- 2, IEC 60950-1, 2006/95/EC (Low Voltage Directive) FCC 47 CFR Part 15 (Class A), ICES-003 (Class A), EN 55022 (Class A), EN 55024, EN 61000-3-2, EN 61000-3-3, AS/NZ... - Page 71 2-19 Stack Member automatic selection of 2-19 Stack operation Member switch selection 2-19 Stack system installation of a new switch in existing stack 2-17 installation of new 2-16 Standards compatibility Switch Password reset specifications for A-2, A-3, A-4,...
- Page 72 Index-2...
