INTRODUCTION:
This document provides specific information for version 5.01.06.0007 of firmware for the following SecureStack
C2 products:
C2G134-24P
Enterasys Networks recommends that you thoroughly review this release note prior to installing or
upgrading this product. There may be a more up-to-date version of this Release Note.
Please go to the Enterasys web site to ensure that this is the latest revision of the Release Note
(http://www.enterasys.com/support/).
FIRMWARE SPECIFICATION:
Status
Current Version
Previous Version
Previous Version
Previous Version
Previous Version
Previous Version
Previous Version
Previous Version
Previous Version
Previous Version
Previous Version
Previous Version
Previous Version
Previous Version
Previous Version
Previous Version
Previous Version
Previous Version
Previous Version
08/13/2008 P/N: 9038155-52
F0615-O
Enterasys
Firmware Version 5.01.06.0007
C2G124-24
C2H124-48
C3G124-24
Version No.
5.01.06.0007
5.01.06.0006
5.01.05.0004
5.01.04.0001
5.01.03.0007
5.01.03.0003
5.01.02.0007
5.01.01.0051
5.01.01.0049
5.01.01.0047
5.01.01.0040
5.01.01.0039
5.00.75
5.00.59
5.00.32
5.00.28
4.00.31
4.00.24
3.03.33
Subject to Change Without Notice
CUSTOMER RELEASE NOTES
®
SecureStack™ C2
August 2008
C2G124-48
C2H124-48P
C2G170-24
C3G124-48
Type
Maintenance Release
Maintenance Release
Maintenance Release
Maintenance Release
Maintenance Release
Maintenance Release
Maintenance Release
Maintenance Release
Maintenance Release
Maintenance Release
Maintenance Release
Feature Release
Customer Release
Customer Release
Customer Release
Customer Release
Customer Release
Customer Release
Customer Release
50 Minuteman Road
Andover, MA 01810 (USA)
Tel: (978) 684-1000
C2G124-48P
C2K122-24
C3G124-24P
C3G124-48P
Release Date
August 2008
August 2008
July 2008
June 2008
May 2008
May 2008
March 2008
March 2008
February 2008
January 2008
December 2007
December 2007
August 2007
March 2007
January 2007
December 2006
August 2006
July 2006
April 2006
Page: 1 of 41
