- Page 1 SecureStack C2 Gigabit Ethernet Switch Hardware Installation Guide C2G170-24 P/N 9034109-01...
- Page 3 Elektrischer Gefahrenhinweis: Installationen sollten nur durch ausgebildetes und qualifiziertes Personal vorgenommen werden. Enterasys Networks reserves the right to make changes in specifications and other information contained in this document and its web site without prior notice. The reader should in all cases consult Enterasys Networks to determine whether any such changes have been made. The hardware, firmware, or software described in this document is subject to change without notice. IN NO EVENT SHALL ENTERASYS NETWORKS BE LIABLE FOR ANY INCIDENTAL, INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES WHATSOEVER (INCLUDING BUT NOT LIMITED TO LOST PROFITS) ARISING OUT OF OR RELATED TO THIS DOCUMENT, WEB SITE, OR THE INFORMATION CONTAINED IN THEM, EVEN IF ENTERASYS NETWORKS HAS BEEN ADVISED OF, KNEW OF, OR SHOULD HAVE KNOWN OF, THE POSSIBILITY OF SUCH DAMAGES. Enterasys Networks, Inc. 50 Minuteman Road Andover, MA 01810 © 2006 Enterasys Networks, Inc. All rights reserved. Part Number: 9034109‐01 March 2006 ENTERASYS NETWORKS, ENTERASYS MATRIX, LANVIEW, MATRIX, NETSIGHT, WEBVIEW, and any logos associated therewith, are trademarks or registered trademarks of Enterasys Networks, Inc., in the United States and other countries. All other product names mentioned in this manual may be trademarks or registered trademarks of their respective companies. Documentation URL: http://www.enterasys.com/support/manuals Documentacion URL: http://www.enterasys.com/support/manuals...
-
Page 4: Regulatory Compliance Information
Communications du Canada. Class A ITE Notice WARNING: This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Clase A. Aviso de ITE ADVERTENCIA: Este es un producto de Clase A. En un ambiente doméstico este producto puede causar interferencia de radio en cuyo caso puede ser requerido tomar medidas adecuadas. Klasse A ITE Anmerkung ACHTUNG: Dieses Produkt zählt zur Klasse A (Industriebereich). In Wohnbereichen kann es hierdurch zu Funkstörungen kommen, daher sollten angemessene Vorkehrungen zum Schutz getroffen werden. Product Safety This product complies with the following: UL 60950, CSA C22.2 No. 60950, 73/23/EEC, EN 60950, IEC 60950, EN 60825, 21 CFR 1040.10. Seguridad del Producto El producto de Enterasys cumple con lo siguiente: UL 60950, CSA C22.2 No. 60950, 73/23/EEC, EN 60950, IEC 60950, EN 60825, 21 CFR 1040.10. Produktsicherheit Dieses Produkt entspricht den folgenden Richtlinien: UL 60950, CSA C22.2 No. 60950, 73/23/EEC, EN 60950, IEC 60950, EN 60825, 21 CFR 1040.10. ... - Page 5 Electromagnetic Compatibility (EMC) This product complies with the following: 47 CFR Parts 2 and 15, CSA C108.8, 89/336/EEC, EN 55022, EN 61000‐3‐2, EN 61000‐3‐3, EN 55024, AS/NZS CISPR 22, VCCI V‐3. Compatibilidad Electromágnetica (EMC) Este producto de Enterasys cumple con lo siguiente: 47 CFR Partes 2 y 15, CSA C108.8, 89/336/EEC, EN 55022, EN 55024, EN 61000‐3‐2, EN 61000‐3‐3, AS/NZS CISPR 22, VCCI V‐3. Elektro- magnetische Kompatibilität (EMC) Dieses Produkt entspricht den folgenden Richtlinien: 47 CFR Parts 2 and 15, CSA C108.8, 89/336/EEC, EN 55022, EN 61000‐3‐2, EN 61000‐3‐3, EN 55024, AS/NZS CISPR 22, VCCI V‐3. VCCI Notice This is a class A product based on the standard of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance may arise. When such trouble occurs, the user may be required to take corrective actions. BSMI EMC Statement — Taiwan This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures.
-
Page 6: Safety Information
(WEEE): The symbol above indicates that separate collection of electrical and electronic equipment is required and that this product was placed on the European market after August 13, 2005, the date of enforcement for Directive 2002/96/EC. When this product has reached the end of its serviceable life, it cannot be disposed of as unsorted municipal waste. It must be collected and treated separately. It has been determined by the European Parliament that there are potential negative effects on the environment and human health as a result of the presence of hazardous substances in electrical and electronic equipment. It is the users’ responsibility to utilize the available collection system to ensure WEEE is properly treated. For information about the available collection system, please go to http://www.enterasys.com/support/ or contact Enterasys Customer Support at 353 61 705586 (Ireland). The single mode interface modules use Class 1 laser transceivers. Read the following safety information before installing or operating these modules. The Class 1 laser transceivers use an optical feedback loop to maintain Class 1 operation limits. This control loop eliminates the need for maintenance checks or adjustments. The output is factory set, and does not allow any user adjustment. Class 1 Laser transceivers comply with the following safety standards: • 21 CFR 1040.10 and 1040.11 U.S. Department of Health and Human Services (FDA). • IEC Publication 825 (International Electrotechnical Commission). • CENELEC EN 60825 (European Committee for Electrotechnical Standardization). -
Page 7: Declaration Of Conformity
Declaration of Conformity Application of Council Directive(s): 89/336/EEC 73/23/EEC Manufacturer’s Name: Enterasys Networks, Inc. Manufacturer’s Address: 50 Minuteman Road Andover, MA 01810 European Representative Address: Enterasys Networks, Ltd. Nexus House, Newbury Business Park London Road, Newbury Berkshire RG14 2PZ, England Conformance to Directive(s)/Product Standards: EC Directive 89/336/EEC EN 55022 EN 61000‐3‐2 EN 61000‐3‐3 EN 55024 EC Directive 73/23/EEC EN 60950 EN 60825 Equipment Type/Environment: Networking Equipment, for use in a Commercial or Light Industrial Environment. Enterasys Networks, Inc. declares that the equipment packaged with this notice conforms to the above directives. - Page 8 BEFORE OPENING OR UTILIZING THE ENCLOSED PRODUCT, This document is an agreement (“Agreement”) between the end user (“You”) and Enterasys Networks, Inc. on behalf of itself and its Affiliates (as hereinafter defined) (“Enterasys”) that sets forth Your rights and obligations with respect to the Enterasys software program/firmware installed on the Enterasys product (including any accompanying documentation, hardware or media) (“Program”) in the package and prevails over any additional, conflicting or inconsistent terms and conditions appearing on any purchase order or other document submitted by You. “Affiliate” means any person, partnership, corporation, limited liability company, or other form of enterprise that directly or indirectly through one or more intermediaries, controls, or is controlled by, or is under common control with the party specified. This Agreement constitutes the entire understanding between the parties, and supersedes all prior discussions, representations, understandings or agreements, whether oral or in writing, between the parties with respect to the subject matter of this Agreement. The Program may be contained in firmware, chips or other media. BY INSTALLING OR OTHERWISE USING THE PROGRAM, YOU REPRESENT THAT YOU ARE AUTHORIZED TO ACCEPT THESE TERMS ON BEHALF OF THE END USER (IF THE END USER IS AN ENTITY ON WHOSE BEHALF YOU ARE AUTHORIZED TO ACT, “YOU” AND “YOUR” SHALL BE DEEMED TO REFER TO SUCH ENTITY) AND THAT YOU AGREE THAT YOU ARE BOUND BY THE TERMS OF THIS AGREEMENT, WHICH INCLUDES, AMONG OTHER PROVISIONS, THE LICENSE, THE DISCLAIMER OF WARRANTY AND THE LIMITATION OF LIABILITY. IF YOU DO NOT AGREE TO THE TERMS OF THIS AGREEMENT OR ARE NOT AUTHORIZED TO ENTER INTO THIS AGREEMENT, ENTERASYS IS UNWILLING TO LICENSE THE PROGRAM TO YOU AND YOU AGREE TO RETURN THE UNOPENED PRODUCT TO ENTERASYS OR YOUR DEALER, IF ANY, WITHIN TEN (10) DAYS FOLLOWING THE DATE OF RECEIPT FOR A FULL REFUND. IF YOU HAVE ANY QUESTIONS ABOUT THIS AGREEMENT, CONTACT ENTERASYS NETWORKS, LEGAL DEPARTMENT AT (978) 684‐1000. You and Enterasys agree as follows: LICENSE. You have the non‐exclusive and non‐transferable right to use only the one (1) copy of the Program provided in this package subject to the terms and conditions of this Agreement. RESTRICTIONS. Except as otherwise authorized in writing by Enterasys, You may not, nor may You permit any third party to: (i) Reverse engineer, decompile, disassemble or modify the Program, in whole or in part, including for reasons ...
- Page 9 APPLICABLE LAW. This Agreement shall be interpreted and governed under the laws and in the state and federal courts of the Commonwealth of Massachusetts without regard to its conflicts of laws provisions. You accept the personal jurisdiction and venue of the Commonwealth of Massachusetts courts. None of the 1980 United Nations Convention on Contracts for the International Sale of Goods, the United Nations Convention on the Limitation Period in the International Sale of Goods, and the Uniform Computer Information Transactions Act shall apply to this Agreement. EXPORT RESTRICTIONS. You understand that Enterasys and its Affiliates are subject to regulation by agencies of the U.S. Government, including the U.S. Department of Commerce, which prohibit export or diversion of certain technical products to certain countries, unless a license to export the Program is obtained from the U.S. Government or an exception from obtaining such license may be relied upon by the exporting party. If the Program is exported from the United States pursuant to the License Exception CIV under the U.S. Export Administration Regulations, You agree that You are a civil end user of the Program and agree that You will use the Program for civil end uses only and not for military purposes. If the Program is exported from the United States pursuant to the License Exception TSR under the U.S. Export Administration Regulations, in addition to the restriction on transfer set forth in Sections 1 or 2 of this Agreement, You agree not to (i) reexport or release the Program, the source code for the Program or technology to a national of a country in Country Groups D:1 or E:2 (Albania, Armenia, Azerbaijan, Belarus, Bulgaria, Cambodia, Cuba, Estonia, Georgia, Iraq, Kazakhstan, Kyrgyzstan, Laos, Latvia, Libya, Lithuania, Moldova, North Korea, the People’s Republic of China, Romania, Russia, Rwanda, Tajikistan, Turkmenistan, Ukraine, Uzbekistan, Vietnam, or such other countries as may be designated by the United States Government), (ii) export to Country Groups D:1 or E:2 (as defined herein) the direct product of the Program or the technology, if such foreign produced direct product is subject to national security controls as identified on the U.S. Commerce Control List, or (iii) if the direct product of the technology is a complete plant or any major component of a plant, export to Country Groups D:1 or E:2 the direct product of the plant or a major component thereof, if such foreign produced direct product is subject to national security controls as identified on the U.S. Commerce Control List or is subject to State Department controls under the U.S. Munitions List. UNITED STATES GOVERNMENT RESTRICTED RIGHTS. The enclosed Program (i) was developed solely at private expense; (ii) contains “restricted computer software” submitted with restricted rights in accordance with section 52.227‐19 (a) through (d) of the Commercial Computer Software‐Restricted Rights Clause and its successors, and (iii) in all respects is proprietary data belonging to Enterasys and/or its suppliers. For Department of Defense units, the Program is considered commercial computer software in accordance with DFARS section 227.7202‐3 and its successors, and use, duplication, or disclosure by the Government is subject to restrictions set forth herein. DISCLAIMER OF WARRANTY. EXCEPT FOR THOSE WARRANTIES EXPRESSLY PROVIDED TO YOU IN WRITING BY Enterasys, Enterasys DISCLAIMS ALL WARRANTIES, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY, SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, TITLE AND NON‐ INFRINGEMENT WITH RESPECT TO THE PROGRAM. IF IMPLIED WARRANTIES MAY NOT BE DISCLAIMED BY APPLICABLE LAW, THEN ANY IMPLIED WARRANTIES ...
- Page 10 OWNERSHIP. This is a license agreement and not an agreement for sale. You acknowledge and agree that the Program constitutes trade secrets and/or copyrighted material of Enterasys and/or its suppliers. You agree to implement reasonable security measures to protect such trade secrets and copyrighted material. All right, title and interest in and to the Program shall remain with Enterasys and/or its suppliers. All rights not specifically granted to You shall be reserved to Enterasys. 10. ENFORCEMENT. You acknowledge and agree that any breach of Sections 2, 4, or 9 of this Agreement by You may cause Enterasys irreparable damage for which recovery of money damages would be inadequate, and that Enterasys may be entitled to seek timely injunctive relief to protect Enterasys’ rights under this Agreement in addition to any and all remedies available at law. 11. ASSIGNMENT. You may not assign, transfer or sublicense this Agreement or any of Your rights or obligations under this Agreement, except that You may assign this Agreement to any person or entity which acquires substantially all of Your stock or assets. Enterasys may assign this Agreement in its sole discretion. This Agreement shall be binding upon and inure to the benefit of the parties, their legal representatives, permitted transferees, successors and assigns as permitted by this Agreement. Any attempted assignment, transfer or sublicense in violation of the terms of this Agreement shall be void and a breach of this Agreement. 12. WAIVER. A waiver by Enterasys of a breach of any of the terms and conditions of this Agreement must be in writing and will not be construed as a waiver of any subsequent breach of such term or condition. Enterasys’ failure to enforce a term upon Your breach of such term shall not be construed as a waiver of Your breach or prevent enforcement on any other occasion. 13. SEVERABILITY. In the event any provision of this Agreement is found to be invalid, illegal or unenforceable, the validity, legality and enforceability of any of the remaining provisions shall not in any way be affected or impaired thereby, and that provision shall be reformed, construed and enforced to the maximum extent permissible. Any such invalidity, illegality or unenforceability in any jurisdiction shall not invalidate or render illegal or unenforceable such provision in any other jurisdiction. 14. TERMINATION. Enterasys may terminate this Agreement immediately upon Your breach of any of the terms and conditions of this Agreement. Upon any such termination, You shall immediately cease all use of the Program and shall return to Enterasys the Program and all copies of the Program. viii...
-
Page 11: Table Of Contents
Installing Optional Mini-GBICs ...3-3 Preparation ...3-3 Installing an Optional Mini-GBIC ...3-4 Preparation ...3-4 Installation ...3-5 Installing the Switch on a Flat Surface ...3-7 Installing the Rubber Feet ...3-7 Guidelines for Installation ...3-8 Rack Mounting the Switch ...3-9 Guidelines for Rackmount Installation ...3-9 Attaching Brackets and Installing in Rack ...3-10... - Page 12 Connecting High-Speed Stacking Cables ...3-11 Configuring Switches in a Stack ...3-12 About SecureStack C2 Switch Operation in a Stack ...3-13 Recommended Procedures for New and Existing Stacks ...3-14 Connecting AC and RPS Power ...3-15 Stack Initialization Overview ...3-17 Connecting to Console Port for Local Management ...3-17 What Is Needed ...3-18...
- Page 13 Mini-GBIC with LC Connector ...3-6 Mini-GBIC with RJ45 Connector ...3-6 Chassis Bottom, Rubber Feet Placement ...3-7 Area Guidelines for Switch Installation on Flat Surface ...3-9 Attaching the Rackmount Brackets ...3-10 Fastening the Switch to the Rack...3-10 High-Speed Stacking Cable Connections ...3-12 AC and PRS Power Connections...3-16...
-
Page 15: About This Guide
25 and 26. Depending on the firmware version used in the C2G170-24 switch, some features described in this document may not be supported. Refer to the Release Notes shipped with the switch to determine which features are supported. -
Page 16: How To Use This Guide
This preface provides an overview of this guide and the SecureStack C2 manual set, a brief summary of each chapter and defines the conventions used throughout this guide. To locate information concerning various subjects in this guide, refer to the following table: For... An overview of the switch features and how to obtain technical support Network requirements that must be met before installing the switch Instructions to install the switch on a flat surface or in a standard 19-inch rack and configure the... -
Page 17: Conventions Used In This Guide
Conventions Used in This Guide Conventions Used in This Guide The following conventions are used in this guide: Note: Calls the reader’s attention to any item of information that may be of special importance. Caution: Contains information essential to avoid damage to the equipment. Precaución: Contiene información esencial para prevenir dañar el equipo. Achtung: Verweißt auf wichtige Informationen zum Schutz gegen Beschädigungen. - Page 18 Conventions Used in This Guide xvi About This Guide...
-
Page 19: Chapter 1: Introduction
This chapter introduces the C2G170‐24 stackable switch. Depending on the firmware version used in the switch, some features described in this document may not be supported. Refer to the Release Notes shipped with the C2G170-24 features are supported. Overview The C2G170‐24 is a stackable switch, which can be adapted and scaled to help meet your network needs. The switch provides 24 Gigabit Ethernet SFP (Small Form Factor Pluggable) interface slots for optional 802.3ae compliant hot‐swappable Mini‐GBIC interfaces. The various versions of hot swappable Mini‐GBICs provide you with the flexibility to install interfaces that support: • 1000BASE‐T Ethernet over copper connections for 10/100/1000 Mbps •... -
Page 20: C2G170-24 Stackable Switch
• Rear panel connectors for high‐speed connections in a stack configuration. • Rear panel Redundant Power Supply connector for a redundant power supply connection. The switch connects to an Enterasys C2RPS‐SYS using a C2RPS‐PSM Cable. Caution: The C2G170-24 is not a PoE-compliant device. Do not connect a SecureStack C2 PoE Redundant Power System (C2RPS-POE) to the power connector. Otherwise, damage to the device may result. Precaución: El dispositivo C2G170-24 no cumple con el estándar PoE. No conecte una fuente de poder redundante (RPS) SecureStack C2 PoE (C2RPS-POE) al cable de corriente directa. -
Page 21: High-Speed Stack Connections
Redundant Power Supply Capability The switch has redundant power supply capability when connected to an optional external redundant power supply (RPS). If the internal power supply fails, the RPS assumes the entire load of the switch without interrupting network traffic. The internal power supply and RPS each have their own AC power connection, which enables the connection of each power supply to a different AC power circuit for additional AC power source redundancy. Connectivity You can connect this switch to Gigabit Ethernet networks or workstations by way of optional Mini‐GBICs installed in the 24 SFP port slots for 1000BASE‐SX/‐EX/‐ELX fiber‐optic connections and 1000BASE‐T copper connections. At the time of this printing, the Mini‐GBICs supported and available from Enterasys are described in Table standard. Table 1-1 Description of Mini-GBICs Mini-GBIC MGBIC-LC01 MGBIC-LC03 MGBIC-LC09 1‐1 on page 1‐3. These Mini‐GBICs meet or exceed the IEEE 802.3z‐1998 Specification Provides one 1000BASE-SX compliant LC fiber-optic multimode port and a standard LC connector. For optical and operating range specifications, refer to “MGBIC-LC01/MGBIC-MT01 Specifications (1000BASE-SX)”... -
Page 22: Management
Management Table 1-1 Description of Mini-GBICs (continued) Mini-GBIC MGBIC-MT01 MGBIC-08 MGBIC-02 Management Management of the module can be either in‐band or out‐of‐band. In‐band remote management is possible using Telnet, Enterasys Networks’ NetSight application, or the WebView application. Out‐of‐band management is provided through the DB9 console port on the front panel using a VT100 terminal or a VT100 terminal emulator. Switch Configuration Using WebView Enterasys Networks’ HTTP‐based Web management application (WebView) is an intuitive web tool for simple management tasks. Switch Configuration Using CLI Commands The CLI commands enable you to perform more complete switch configuration management tasks. For CLI command set information and how to configure the module, refer to the SecureStack C2 Configuration Guide. Standards Compatibility The switches are fully compliant with the IEEE 802.3‐2002, 802.3ae‐2002, 802.1D‐1998, and 802.1Q‐1998 standards. The switches provide IEEE 802.1D‐1998 Spanning Tree Algorithm (STA) support to enhance the overall reliability of the network and protect against “loop” conditions. 1-4 Introduction... -
Page 23: Lanview Diagnostic Leds
• Any previous Return Material Authorization (RMA) numbers http://www.enterasys.com/support 1-800-872-8440 (toll-free in U.S. and Canada) For the Enterasys Networks Support toll-free number in your country: http://www.enterasys.com/support/gtac-all.html support@enterasys.com To expedite your message, please type [C-SERIES] in the subject line. LANVIEW Diagnostic LEDs SecureStack C2 Installation Guide 1-5... - Page 24 Getting Help 1-6 Introduction...
-
Page 25: Chapter 2: Network Requirements
Failure to do so will produce poor network performance. Note: The SecureStack C2 Configuration Guide and the Cabling Guide referred to in the following sections can be found on the Enterasys Networks World Wide Web site: http://www.enterasys.com/support/manuals For details about obtaining the manuals, refer to 10BASE-T Network When connecting a 10BASE‐T segment to a MGBIC‐02 RJ45 port, ensure that the network ... -
Page 26: 100Base-Tx Network
2002 100BASE‐TX Fast Ethernet network requirements for the switches to operate at 100 Mbps. Note: When using the fixed ports on the switch for 100 Mbps operation use Category 5 UTP cabling with an impedance between 85 and 111 ohms for 100 Mbps operation. The MGBIC-02 is capable of operating at 10, 100, or 1000 Mbps. This is accomplished by the switch when Auto-Negotiation is enabled. -
Page 27: Hardware Installation
Riesgo Electrico: Solamente personal calificado debe realizar procedimientos de instalacion. Elektrischer Gefahrenhinweis: Installationen sollten nur durch ausgebildetes und qualifiziertes Personal vorgenommen werden. Read the Release Notes shipped with the switch to check for any exceptions to the supported features and operation documented in this guide. This chapter provides instructions to install the C2G170‐24. Follow the order of the sections listed below to correctly install the switch. -
Page 28: Considerations Prior To Installation
Rubber feet with adhesive backing for installation on a flat surface AC power cord (type of power cord is country-dependent) This installation guide Customer Release Notes URL notice card Remove the tape seal on the non‐conductive bag to remove the switch. Perform a visual inspection of the switch for any signs of physical damage. Contact Enterasys Networks if there are any signs of damage. Refer to “Getting Help” on page 1‐5 for details. 3-2 Hardware Installation 3‐1. Quantity... -
Page 29: Installing Optional Mini-Gbics
The Mini-GBIC and switch are sensitive to static discharges. Use an antistatic wrist strap and observe all static precautions during this procedure. Failure to do so could result in damage to the Mini-GBIC and switch. Always leave the Mini-GBIC in the antistatic bag or an equivalent antistatic container when not installed Precaución: Siga las instrucciones del manual para no dañar el Mini-GBIC ni del aparato,... -
Page 30: Installing An Optional Mini-Gbic
The Mini-GBIC and switch are sensitive to static discharges. Use an antistatic wrist strap and observe all static precautions during this procedure. Failure to do so could result in damage to the Mini-GBIC and switch. Always leave the Mini-GBIC in the antistatic bag or an equivalent antistatic container when not installed. -
Page 31: Installation
Installation To install a Mini‐GBIC with an MT‐RJ connection, refer to Figure connection, Figure 3‐2; or for an RJ45 connection, Figure Note: If the Mini-GBIC is one with an RJ45 connector such as an MGBIC-02 ( the installation procedure is the same as described below. However, the Mini-GBIC has a wire handle to release it. Hold the Mini‐GBIC with its top side facing up and its 7‐pin edge connector facing the port slot. Carefully align the Mini‐GBIC with the port slot. -
Page 32: Mini-Gbic With Lc Connector
Installing an Optional Mini-GBIC Figure 3-2 1 Mini-GBIC (MGBIC-08, -LC01, -LC03, or -LC09) 2 Mini-GBIC 3 7-Pin edge connector (insertion side) Figure 3-3 1 Mini-GBIC (MGBIC-02) 2 Mini-GBIC 3 7-Pin edge connector (insertion side) 3-6 Hardware Installation Mini-GBIC with LC Connector Á... -
Page 33: Installing The Switch On A Flat Surface
Installing the Switch on a Flat Surface When installing the switch on a flat surface, the installation of the rubber feet is recommended to prevent the switch from sliding on a flat surface. Installing the rubber feet is optional if you are installing the switch in a rack. To install the rubber feet, proceed to “Installing the Rubber Feet” instructions below. For instructions to rack mount the switch, proceed to “Rack Mounting the Switch” on page 3‐9. Installing the Rubber Feet To install the rubber feet, refer to Figure Place the switch on its back on a sturdy flat surface to gain access to the bottom of the chassis. Remove the four rubber feet from their plastic bag in the shipping box. Locate the four marked locations on the bottom four corners of the chassis. Figure 3-4 Â Â 1 Bottom of chassis as seen when chassis is resting on its back 2 Locations to install the rubber feet (four locations) 3‐4 and proceed as follows:... -
Page 34: Guidelines For Installation
Caution: To ensure proper ventilation and prevent overheating, leave a minimum clearance space of 5.1 cm (2.0 in) at the left, right, and rear of the switch. Do not connect the switch to the AC power source until instructed to do so later in the installation process. -
Page 35: Rack Mounting The Switch
• A temperature of between 5°C (41°F) and 40°C (104°F) must be maintained at the installation site with fluctuations of less than 10°C (18°F) per hour. Note: To ensure proper ventilation and prevent overheating, leave a minimum clearance space of 5.1 cm (2.0 in.) at the left, right, and rear of the switch. Area Guidelines for Switch Installation on Flat Surface À Ã... -
Page 36: Attaching Brackets And Installing In Rack
Figure 3-7 Á À 1 Rails of 19-inch rack 3-10 Hardware Installation Attaching the Rackmount Brackets Fastening the Switch to the Rack 2 Mounting screws (supplied by user) 3‐6, using the eight 2 M3 x 6 mm flathead screws 3‐7. Then fasten the switch securely Á À... -
Page 37: Connecting High-Speed Stacking Cables
• C2CAB-SHORT cable (30.6 cm (12 in.) long) to connect two adjacent switches in the stack. • C2CAB-LONG cable (1.0 m (36.2 in.) long) to connect from the top switch to the bottom switch in the stack. You only need one C2CAB-LONG cable per stack. -
Page 38: Configuring Switches In A Stack
 À Ä 1 High-speed stacking cable 2 STACK DOWN connector 3 STACK UP connector After connecting the cables to the stacking ports, proceed to “Configuring Switches in a Stack” on page 3‐12 for instructions. Configuring Switches in a Stack The information in the following sections is important to understand SecureStack switch operation in a stack installation. 3-12 Hardware Installation High-Speed Stacking Cable Connections à Á Á Á À 4 STACK DOWN connector at top of stack... -
Page 39: About Securestack C2 Switch Operation In A Stack
About SecureStack C2 Switch Operation in a Stack The SecureStack C2 products are stackable switches that can be adapted and scaled to help meet your network needs. These switches provide a management platform and uplink to a network backbone for a stacked group of up to eight SecureStack switches. Once installed in a stack, the switches behave and perform as a single switch. As such, you can start with a single switch and add more switches as your network expands. You can also mix different products in the family in a single stack to provide a desired combination of port types and functions to match the requirements of individual applications. In all cases, a stack of switches performs as one large product, and is managed as a single network entity. When switches are installed and connected as described back in “Connecting High‐Speed Stacking Cables” on page 3‐11, the following occurs during initialization: • The switch that will manage the stack is automatically established and is referred to as the Manager switch. • All other switches are established as Member switches in the stack. • The hierarchy of the switches that will assume the function of backup manager is also determined in case the current manager malfunctions, is powered down, or is disconnected from the stack. • The console port on the manager switch remains active for out‐of‐band (local) switch management, but the console port on each member switch is deactivated. This enables you to set the IP address and system password using a single console port. Now each switch can be configured locally using only the manager’s console port, or inband using a remote device and the CLI set of commands described in this section. For procedures used for various types of connections to the Console port, refer to “Connecting to Console Port for Local Management” on page 3‐17. Once a stack is created (more than one switch is interconnected), the following occurs: Switch (unit) IDs are arbitrarily assigned on a first‐come, first‐served basis. -
Page 40: Recommended Procedures For New And Existing Stacks
The following procedures assume that all switches have a clean configuration from manufacturing. When adding a new switch to an already running stack, it is also assumed that the new switch is using the same firmware image version as other switches in the stack. -
Page 41: Connecting Ac And Rps Power
• Use clear config to clear config parameters without clearing stack switch IDs. This command WILL NOT clear stack parameters and avoids the process of re-numbering the stack. • Use clear config all when it is necessary to clear all config parameters, including stack switch IDs and switch priority values. -
Page 42: Ac And Prs Power Connections
Note: If the CPU LED illuminates solid red, there was a critical failure. For more information about the LED indications and troubleshooting, refer to additional help, contact Enterasys Networks. Refer to details If the switch is a standalone switch, it will take approximately 30 seconds for the switch to start up. If the switch is a stack Manager, it can take up to 3 minutes or more to start up, depending on the number of Member switches in the stack. RPS Power If you are installing an optional redundant power system (C2RPS‐SYS), refer to the ... -
Page 43: Stack Initialization Overview
Note: When switches are connected in a stack configuration and all high-speed stacking cables are connected before powering up the switches, one switch in the stack will be automatically designated as the Manager of the stack and its Console port will remain active. -
Page 44: What Is Needed
Connecting to Console Port for Local Management What Is Needed The following is a list of user‐supplied DTE interface cables that may be needed to connect the DB9 male Console port connector on the switch. The cables are terminated by a DB9 female connector at one end, and by one of three type connectors at the other end, depending on the type connection needed for the remote device. The cables that may be needed are as follows: • DB9 female‐to‐DB9 female • DB9 female‐to‐DB25 female • DB9 female‐to‐DB25 male Using a DTE modem DB9 female‐to‐DB9 female cable, you can connect products equipped with a DB9 DTE male console port to an IBM or compatible PC running a VT series emulation software package. Using a DTE modem DB9 female‐to‐DB25 female cable, you can connect products equipped with a DB9 DTE male console port to a VT series terminal or VT type terminals running emulation programs for the VT series. Using a DTE modem DB9 female‐to‐DB25 male cable, you can connect products equipped with a DB9 DTE male console port to a Hayes compatible modem that supports 9600 baud. The cable used must connect the Console port Received Data, Pin 2 to the Transmitted Data pin at the other end of the cable. The connection from the Console port Transmitted Data, Pin 3 (must be connected) to the Received Data pin cable connection at the other end of the cable. The DB9 Console port pin assignments are shown in Figure Figure 3-10 Â Á À... -
Page 45: Connecting To An Ibm Or Compatible Device
Connecting to an IBM or Compatible Device To connect an IBM PC or compatible device, running the VT terminal emulation, to an Enterasys switch Console port (Figure Connect the DB9 female connector at one end of the cable (not supplied) to the Console port on the Enterasys switch. (If there is a switch designated as the Manager, connect to its Console port.) Plug the DB9 female connector at the other end of cable into the communications port on the PC. Turn on the PC and configure your VT emulation package with the following parameters: Parameter Mode Transmit Bits Parity Stop Bit When these parameters are set, the Startup screen will display. Proceed to “Connecting to the Network” on page 3‐22. Figure 3-11 Connecting an IBM PC or Compatible 1 DB9 female connector 2 Serial interface cable... -
Page 46: Connecting To A Vt Series Terminal
Connecting to Console Port for Local Management Connecting to a VT Series Terminal To connect a VT Series terminal to an Enterasys switch Console port (Figure UTP serial interface cable terminated with a DB9 female connector and a DB25 female connector and proceed as follows: Connect the DB9 female connector at one end of cable to the Console port on the Enterasys switch. (If there is a switch designated as the Manager, connect to its Console port.) Plug the DB25 female connector at the other end of the cable into the port labeled COMM on the VT terminal. Turn on the terminal and access the Setup Directory. Set the following parameters on your terminal: Parameter Mode Transmit Bits Parity Stop Bit When these parameters are set, the Startup screen will display. Proceed to “Connecting to the Network” on page 3‐22. Figure 3-12 1 DB9 female connector 2 Serial interface cable... -
Page 47: Connecting To A Modem
Connecting to a Modem To connect a modem to an Enterasys Networks switch modem port (Figure UTP cable terminated with a DB9 female connector and a DB25 male connector, and proceed as follows: Connect the DB9 female connector at one end of the cable to the Console port on the Enterasys switch. (If there is a switch designated as the Manager, connect to its Console port.) Plug the DB25 male connector at the other end of the cable into the modem communications port. Turn on the modem and make sure the remote modem is ON. With your PC connected to the remote modem, configure your VT emulation package with the following parameters: Parameter Mode Transmit Bits Parity Stop Bit When these parameters are set, the Startup screen will display. If the switches are in a stacked configuration, proceed to “Connecting to the Network” on page 3‐22. Figure 3-13 Connecting to a Modem Æ 1 DB9 female cable connector 4 DB25 male connector 7 PC with VT emulation application... -
Page 48: Connecting To The Network
Connecting to the Network Connecting to the Network The following procedures cover the cable connections from the network or other devices to the switch RJ45 ports or any installed optional Mini‐GBIC. • Connecting UTP Cables on page 3‐22 • Connecting Fiber‐Optic Cables to LC Ports on page 3‐28 Connecting UTP Cables The RJ45 copper connection to an MGBIC‐02 is a 10/100/1000 Mbps connection with internal crossovers. When connecting a workstation to one of these ports, use a straight‐ through cable. When connecting networking devices to these ports, such as a bridge, repeater, or router, use a crossover cable. Note: The MGBIC-02 cabling with an impedance between 85 and 111 ohms. Where new cabling is being installed, it is recommended that Catagory 5e be installed. -
Page 49: Connecting A Utp Cable Segment To An Mgbic-02 Rj45 Port
Verify that the device at the other end of the twisted pair segment is on and properly connected to the segment. Verify that the RJ45 connectors on the twisted pair segment have the proper pinouts and check the cable for continuity. Typically, a crossover cable is used between hub devices. A straight‐through cable is used to connect between switches or hub devices and an end user (computer). Refer to Figure Figure 3‐16 for four‐wire RJ45 connections. Refer to Figure 3‐17 and Figure for eight‐wire RJ45 connections. d. Ensure that the twisted pair connection meets the dB loss and cable specifications outlined in the Cabling Guide. Refer to “Related Documents” on page xiv for information on obtaining this document. If a link is not established, contact Enterasys Networks. Refer to “Getting Help” on page 1‐5 for details. Repeat all steps above until all connections have been made. Â Á 3 Port 2 Link/Activity LED SecureStack C2 Installation Guide 3-23 Connecting to the Network 3‐15 and 3‐18 ... -
Page 50: Four-Wire Crossover Cable Rj45 Pinouts For 10/100Base-Tx
Connecting to the Network Figure 3-15 1 RJ45 switch port 2 Other device port Figure 3-16 1 RJ45 switch port 2 Other device port 3-24 Hardware Installation Four-Wire Crossover Cable RJ45 Pinouts for 10/100BASE-TX À Ã 3 RJ45-to-RJ45 crossover cable 4 RX+/RX- and TX+/TX-connections These connections must share a common color pair. -
Page 51: Eight-Wire Straight-Through Cable Rj45 Pinouts For 10/100/1000Base-Tx
Figure 3-17 Eight-Wire Crossover Cable RJ45 Pinouts for 10/100/1000BASE-TX À 1 RJ45 device port 2 Other device port Figure 3-18 Eight-Wire Straight-Through Cable RJ45 Pinouts for 10/100/1000BASE-TX À 1 RJ45 device port 2 Other device port Á Â 3 RJ45-to-RJ45 crossover cable Á... -
Page 52: Connecting Fiber-Optic Cables To Mt-Rj Ports
(MGBIC‐MT01). Each fiber‐optic link consists of two fiber‐optic strands within the cable: • Transmit (TX) • Receive (RX) The transmit strand from a device port connects to the receive port of a fiber‐optic Gigabit Ethernet device at the other end of the segment. The receive strand of the applicable MT‐RJ port connects to the transmit port of the fiber‐optic Gigabit Ethernet device. Enterasys Networks recommends labeling fiber‐optic cables to indicate receive and transmit ends. Many cables are pre‐labeled, providing matching labels or tapes at both ends of each strand of cable. To connect an MT‐RJ cable to a fixed MT‐RJ connector of a Mini‐GBIC, refer to Figure and proceed as follows: Remove the protective covers (not shown) from the front panel MT‐RJ fiber‐optic port (port 2 in this example) and from the connectors on each end of the cable. Note: Leave the protective covers in place when the connectors are not in use to prevent contamination. Caution: Do not touch the ends of the fiber-optic strands, and do not let the ends come in contact with dust, dirt, or other contaminants. -
Page 53: Cable Connection To Mt-Rj Multimode Fiber-Optic Connectors
Insert the MT‐RJ cable connector into the MT‐RJ connector until it clicks into place. Note: To remove the MT-RJ cable connector, press on its release tab and pull out the cable connector. Figure 3-19 Cable Connection to MT-RJ Multimode Fiber-Optic Connectors  1 Mini-GBIC MT-RJ port connector 2 MT-RJ cable connector Plug the other end of the cable into the appropriate port on the other device. Some cables may be terminated at the other end with two separate connectors, one for each fiber‐optic strand. In this case, ensure that the transmit fiber‐optic strand is connected ... -
Page 54: Connecting Fiber-Optic Cables To Lc Ports
Connecting to the Network If a link has not been established, refer to Chapter a problem persists, refer to “Getting Help” on page 1‐5 for details on contacting Enterasys Networks for support. Repeat steps 1 through 4, above, until all connections have been made. Connecting Fiber-Optic Cables to LC Ports Warning: Do not use optical instruments to view laser output. The use of optical instruments to view laser output increases eye hazard. Advertencia: No utilizar instrumentos opticos para ver el laser. El uso de instrumentos opticos para ver el laser incrementa el riesgo de perdida de la vision. -
Page 55: Cable Connection To Lc Fiber-Optic Connectors
Caution: Do not touch the ends of the fiber-optic strands, and do not let the ends come in contact with dust, dirt, or other contaminants. Contamination of cable ends causes problems in data transmissions. If the ends of the fiber-optic strands become contaminated, use a canned duster to blow the surfaces clean. -
Page 56: Completing The Installation
Verify that a link exists by checking that the port Link/Activity LED is on (blinking green or solid green). If the Link/Activity LED is off, perform the following steps until it is on: Verify that the device at the other end of the segment is ON and connected to the segment. b. If there are separate fiber‐optic connections on the other device, check the crossover of the cables. Swap the cable connections if necessary. Check that the fiber‐optic connection meets the dB loss and cable specifications outlined in the Cabling Guide for multimode mode cabling. To obtain this document, refer to “Related Documents” on page xiv. If a link has not been established, refer to Chapter details. If a problem persists, refer to “Getting Help” on page 1‐5 for details on contacting Enterasys Networks for support. Repeat steps 1 through 4, above, until all connections have been made. Completing the Installation After installing the switch and making the connections to the network, access the switch management, as described below. Initial Logon to Switch Management To initially access switch management from your local PC, terminal, or modem connection, proceed as follows at the displayed startup screen: Enter rw (Read‐Write) for Username. At the Password prompt, press Enter (Return). For details on how to configure the switch using the command line interface, refer to the SecureStack C2 Configuration Guide. The CLI commands enable you to set a new password and perform more involved management configurations on the switch. One of many capabilities is to reconfigure the stack, reassigning the Manager function to another switch and configuring the order of Member switches that will take over the stack management functions in case the operating Manager is powered down, ... - Page 57 After the initial configuration, you can also use WebView (Enterasys Networks’ embedded web server) for configuration and management tasks. All the guides associated with the switch are available online at: http://www.enterasys.com/support/manuals Once you are confident that the installation is successful, route and secure your cables. If you require assistance, contact Enterasys Networks using one of the methods described in “Getting Help” on page 1‐5. Completing the Installation SecureStack C2 Installation Guide 3-31...
- Page 58 Completing the Installation 3-32 Hardware Installation...
-
Page 59: Chapter 4: Troubleshooting
For information about... Using LANVIEW Troubleshooting Checklist Using the Password Reset Switch Caution: There is a risk of explosion if the battery is replaced with an incorrect type. A used battery may be safely disposed in a municipal waste stream. -
Page 60: Using Lanview
Using LANVIEW Using LANVIEW The switch supports the Enterasys Networks built‐in LANVIEW LED visual diagnostic and status monitoring system. The location of each C2G170‐24 LANVIEW LED is shown in Figure 4‐1. The LEDs enable you to quickly observe network status for diagnosing switch and network problems. Figure 4-1 À 1 CPU LED 2 Stack down LED 3 Stack up LED Table 4‐2 describes the LED indications and provides recommended actions as appropriate. Note: The terms flashing, blinking, and solid used in Flashing: LED is flashing randomly. -
Page 61: Lanview Leds
Contact Enterasys Networks for technical support. If the LED remains red for several minutes, the system may have a fatal error. Contact Enterasys Networks for technical support. If the LED remains amber for more than several minutes, contact Enterasys Networks for technical support. - Page 62 Solid. Valid connection to switch stackdown connector. Blinking. Information is being transferred over the high-speed stacking cable. Manager Switch is operating as a Member in the stack. Green Solid. Switch is operating as the Manager of the stack. RPS not in use.
-
Page 63: Troubleshooting Checklist
None. None. None. 4‐1 for a checklist of problems, Recommended Action Ensure that the switch was installed properly according to the installation instructions in Chapter Ensure that the power cords are connected properly to an active power source that meets the AC input specifications for this switch. - Page 64 Configuration Guide for instructions to enable/disable ports. Verify that all network connections between the network management station and the device are valid and operating. If the problem continues, contact Enterasys Networks for technical support. Verify that Spanning Tree is enabled. Refer to the SecureStack C2 Configuration Guide for the instructions to set the type of STA.
-
Page 65: Using The Password Reset Switch
1 Password Reset switch To reset the switch password, refer to Figure Note: Notify the system manager before changing the password. Press‐and‐hold the Reset button while the switch is operational. This change of the login password to the default password will be indicated via CLI only. Logon to device management. You can now logon to the switch via the Console port and assign a new password using the command line interface (CLI). To access switch management from your local PC, terminal, or modem connection, refer to the SecureStack C2 Configuration Guide for instructions on how to log in and enter a new password. The guide is available online at: http://www.enterasys.com/support/manuals If you require assistance, contact Enterasys Networks using one of the methods described in “Getting Help” on page 1‐5. Password Reset Switch Using the Password Reset Switch À 4‐3 and proceed as follows: SecureStack C2 Installation Guide 4-7... - Page 66 Using the Password Reset Switch 4-8 Troubleshooting...
-
Page 67: Appendix A: Specifications
This appendix provides information about the following: For information about... Switch Specifications Mini-GBIC Input/Output Specifications Console Port Pinout Assignments Regulatory Compliance Enterasys Networks reserves the right to change the specifications at any time without notice. Switch Specifications Table A‐1 provides the I/O ports, processors and memory, physical, and environmental specifications for the C2G170‐24. Table A-1 Switch Specifications Item C2G170-24 SFP port slots 1 through 24 Specifications Specification Twenty-four, Mini-GBIC port slots for 10/100/1000 Mbps Ethernet... -
Page 68: Mini-Gbic Input/Output Specifications
Mini-GBIC Input/Output Specifications Table A-1 Switch Specifications (continued) Item Processors/Memory Processor Dynamic Random Access Memory (DRAM) FLASH Memory Physical Dimensions Approximate Weight Predicted hours for Mean Time Between Failures (MTBF) Heat Dissipation (maximum) Environmental Operating Temperature Storage Temperature Operating Relative Humidity Mini-GBIC Input/Output Specifications The Mini‐Gigabit Ethernet Card (Mini‐GBIC) port interface slots can support 1‐Gbps ... -
Page 69: Gigabit Ethernet Specifications
Table A-2 Mini-GBIC Input/Output Port Specifications Item MGBIC-MT01 MGBIC-08 MGBIC-02 Gigabit Ethernet Specifications The following specifications for the Mini‐GBICs (shown in Table A‐3 through Table meet or exceed the IEEE 802.3z‐1998 standard. MGBIC-LC01/MGBIC-MT01 Specifications (1000BASE-SX) Table A-3 MGBIC-LC01 / MGBIC-MT01 Optical Specifications Item Transmit Power (minimum) Receive Sensitivity Link Power Budget Table A-4 MGBIC-LC01 / MGBIC-MT01 Operating Range Item 62.5 µm MMF 62.5 µm MMF... -
Page 70: Mgbic-Lc03 Specifications (1000Base-Sx
Gigabit Ethernet Specifications MGBIC-LC03 Specifications (1000BASE-SX) Table A-5 MGBIC-LC03 Optical Specifications Item Transmit Power (minimum) Transmit Power (maximum) Receive Sensitivity Link Power Budget (Multimode Only) 1. The maximum drive distance (up to 2 km) depends on the quality of the installed multimode fiber- optic cable segment. -
Page 71: Mgbic-08 Specifications (1000Base-Elx
Table A-8 MGBIC-LC09 Operating Range Item 62.5 µm MMF 50 µm MMF 50 µm MMF 10 µm SMF MGBIC-08 Specifications (1000BASE-ELX) Table A-9 MGBIC-08 Optical Specifications Item Transmit Power (minimum) Receive Sensitivity Maximum Input Power Link Power Budget (Full Duplex Only) 1. -
Page 72: Console Port Pinout Assignments
Console Port Pinout Assignments Table A-11 MGBIC-02 / Specifications (continued) Item Data Rate TX Output impedance RX Input impedance Console Port Pinout Assignments The Console port is a DB9 serial communications port for local access to Local Management. Refer to Figure Figure A-1 Pin 2, Received Data (input) Pin 3, Transmitted Data (output) Regulatory Compliance The C2G170‐24 meets the safety and electromagnetic compatibility (EMC) requirements listed in Table Table A-12 Compliance Standards Regulatory Compliance... - Page 73 3-12 Connecting to the network 3-22 Connectivity introduction to Console port pinout assignments Document conventions Electromagnetic Compatibility (EMC) requirements Enterasys contacting getting help from technical support from Fiber budget High-speed stack connections introduction to High-speed stacking cables installation of 3-11...
- Page 74 3-17 Stack Member automatic selection of 3-17 Stack operation Member switch selection 3-17 Stack system installation of a new switch in existing stack installation of new 3-14 Standards compatibility Switch overview of Password reset specifications for Switch carton...
