set cos port-config

Example
This example shows how to show all CoS settings:
C3(su)->show cos settings
CoS Index Priority
--------- ---------- ------- -------
0
1
2
3
4
5
6
7
set cos port-config
Use this command to create a port group for inbound rate limiting or flood control and add or
remove ports from the group.
Syntax
set cos port-config {irl|flood-ctrl} group-type-index [name name] [ports port-
list] [append] | [clear]
Parameters
irl
flood‐ctrl
group‐type‐index
name name
ports port‐list
append
clear
Defaults
None.
Mode
Switch command, read‐write.
Usage
CoS port groups are identified by group number and the type of ports in the group, in the form of
group#.port‐type. The port group 0.0 exists by default. This default port group cannot be removed
and all physical ports in the system are assigned to it. Up to seven additional port groups (1
11-24 Policy Classification Configuration
ToS IRL
0 48 *
1 * *
2 * *
3 * *
4 * *
5 * *
6 * *
7 * *
Specifies that this is an inbound rate limiting (IRL) port group.
Specifies that this is a flood control port group.
Specifies an inbound rate limiting port group/type index. Valid entries are
in the form of group#.port‐type.
Valid values for group# can range from 0 to 7. Valid values for port‐type
can range from 0 to 1, although only port type 0 is currently supported.
For example, port group 3 would be specified as 3.0.
(Optional) User defined name for the group.
(Optional) Ports assigned to the group. All ports must be of the same port
type (Fast Ethernet, Gigabit Ethernet).
(Optional) Append (add) the ports to the ports that are already in the
group.
(Optional) Clear the given ports from those assigned to the group.
flood-ctrl
----------
enabled
enabled
enabled
enabled
enabled
enabled
enabled
enabled
