set lldp port tx-tlv

Defaults
None.
Mode
Switch command, read‐write.
Example
After you configure a location information value, you must also configure the port to send the
Location Information TLV with the set lldp port tx‐tlv command. This example configures the
ELIN identifier 5551234567 on ports ge.1.1 through ge.1.6 and then configures the ports to send
the Location Information TLV.
C3(rw)->set lldp port location-info 5551234567 ge.1.1-6
C3(rw)->set lldp port tx-tlv med-loc ge.1.1-6
set lldp port tx-tlv
Use this command to select the optional LLDP and LLDP‐MED TLVs to be transmitted in
LLDPDUs by the specified port or ports. Use the show lldp port local‐info command to display
the values of these TLVs for the port.
Syntax
set lldp port tx-tlv {[all] | [port-desc] [sys-name] [sys-desc] [sys-cap] [mgmt-
addr] [vlan-id] [stp] [lacp] [gvrp] [mac-phy] [poe] [link-aggr] [max-frame] [med-
cap] [med-pol] [med-loc] [med-poe]} port-string
Parameters
all
port‐desc
sys‐name
sys‐desc
sys‐cap
mgmt‐addr
vlan‐id
stp
lacp
6-28 Discovery Protocol Configuration
Adds all optional TLVs to transmitted LLDPDUs.
Port Description optional basic LLDP TLV. Value sent is ifDescr object
defined in RFC 2863.
System Name optional basic LLDP TLV. Value sent is the
administratively assigned name for the system.
System Description optional basic LLDP TLV. Value sent is sysDescr
object defined in RFC 3418.
System Capabilities optional basic LLDP TLV. For a network
connectivity device, value sent can be bridge and/or router.
Management Address optional basic LLDP TLV. Value sent is IPv4
address of host interface.
Port VLAN ID IEEE 802.1 Extensions TLV. Value sent is port VLAN
ID (PVID).
Spanning Tree information defined by Protocol Identity IEEE 802.1
Extensions TLV. If STP is enabled on the port, value sent includes
version of protocol being used.
LACP information defined by Protocol Identity IEEE 802.1
Extensions TLV. If LACP is enabled on the port, value sent includes
version of protocol being used.
