show ip pimsm componenttable

Mode
Any router mode.
Example
This example shows how to display PIM information.
C2(su)->router# show ip pimsm
Admin Mode Enable
Join/Prune Interval (secs) 60
PIM-SM INTERFACE STATUS
VlanId
---------
8
16
17
20
30
31
32
33
Table 17‐7 provides an explanation of the command output.
Table 17-7 show ip pimsm Output Detail
Output
Admin Mode
Join/Prune Interval
(secs)
VlanId
Interface Mode
Protocol State
show ip pimsm componenttable
This command displays the table containing objects specific to a PIM domain. One row exists for
each domain to which the router is connected.
Syntax
show ip pimsm componenttable
Parameters
None.
Defaults
None.
17-48 IPv4 Routing Protocol Configuration
Interface Mode Protocol State
-------------- ----------------
Disable Non-Operational
Enable Operational
Enable Operational
Enable Operational
Enable Operational
Disable Non-Operational
Disable Non-Operational
Disable Non-Operational
What it displays
This field indicates whether PIM-SM is enabled or disabled. This is a configured
value.
This field shows the interval at which periodic PIM-SM Join/Prune messages are to
be sent.
VLAN id associated with the PIM IP Interface.
This field indicates whether PIM-SM is enabled or disabled on the interface. This is a
configured value.
This field indicates the current state of the PIM-SM protocol on the interface.
Possible values are Operational or Non-Operational.
