Parameters
status
disable
enable
vvid
vlan‐id
none
dot1p
untagged
trusted
yes
no
cos value
port‐string
Defaults
• Status: enabled
• Voice VLAN: none
• Trust mode: trusted
• CoS value: 0
Mode
Switch mode, read‐write.
Usage
The following points describe how the Cisco DP extended trust settings work on the switch.
• A Cisco DP port trust status of trusted or untrusted is only meaningful when a Cisco IP phone
is connected to a switch port and a PC or other device is connected to the back of the Cisco IP
phone.
• A Cisco DP port state of trusted or untrusted only affects tagged traffic transmitted by the
device connected to the Cisco IP phone. Untagged traffic transmitted by the device connected
to the Cisco IP phone is unaffected by this setting.
• If the switch port is configured to a Cisco DP trust state of trusted (with the trusted yes
parameter of this command), this setting is communicated to the Cisco IP phone instructing it
to allow the device connected to it to transmit traffic containing any CoS or Layer 2 802.1p
marking.
Sets the CiscoDP port operational status.
Does not transmit or process CiscoDP PDUs.
Transmits and processes CiscoDP PDUs.
Sets the port voice VLAN for CiscoDP PDU transmission.
Specifies the VLAN ID, range 1‐4093.
No voice VLAN will be used in CiscoDP PDUs. This is the default.
Instructs attached phone to send 802.1p tagged frames.
Instructs attached phone to send untagged frames.
Sets the extended trust mode on the port.
Instructs attached phone to allow the device connected to it to transmit
traffic containing any CoS or Layer 2 802.1p marking. This is the default
value.
Instructs attached phone to overwrite the 802.1p tag of traffic
transmitted by the device connected to it to 0, by default, or to the value
configured with the cos parameter.
Instructs attached phone to overwrite the 802.1p tag of traffic
transmitted by the device connected to it with the specified value, when
the trust mode of the port is set to untrusted. Value can range from 0 to
7, with 0 indicating the lowest priority.
Specifies the port(s) on which status will be set.
set ciscodp port
