This chapter provides information about the commands used to configure and monitor the sFlow
system.
For information about...

Overview

Commands
Overview
sFlow is a method for monitoring high‐speed switched and routed networks. sFlow technology is
built into network equipment and gives visibility into network activity, enabling effective
management and control of network resources.
An sFlow solution consists of an sFlow Agent, embedded in the network device such as a switch
or router, and an sFlow Collector. The sFlow Agent uses sampling technology to capture traffic
statistics from the device it is monitoring and immediately forwards the sampled traffic statistics
to an sFlow Collector for analysis in sFlow datagrams.
The sFlow Agent uses two forms of sampling— statistical packet‐based sampling of switched or
routed Packet Flows, and time‐based sampling of counters.
Version 5 of sFlow is described in detail in the document entitled "sFlow Version 5" available from
sFlow.org (http://www.sflow.org).

Using sFlow in Your Network

The advantages of using sFlow include:
• sFlow makes it possible to monitor ports of a switch, with no impact on the distributed
switching performance. (See "Usage Notes" on page 28‐3 for more information.)
• sFlow requires very little memory or CPU usage. Samples are not aggregated into a flow‐
table on the switch — they are forwarded immediately over the network to the sFlow
Collector.
• The system is tolerant to packet loss in the network. (The statistical model means loss is
equivalent to a slight change in the sampling rate.)
• The sFlow Collector can receive data from multiple switches, providing a real‐time
synchronized view of the whole network.
• The sFlow Collector can analyze traffic patterns for whatever protocols are found in the
packet headers (for example, TCP/IP, IPX, Ethernet, AppleTalk). There is no need for the layer
2 switch to decode and understand all protocols.
sFlow Configuration
SecureStack C3 Configuration Guide 28-1
28
Refer to page...
28-1
28-4
