and reception. The MUX Interface provides the link between the BDLC digital section and the analog Physical Interface. The wave shaping,
driving and digitizing of data is performed by the Physical Interface.
The Physical Interface is not implemented in the BDLC module and must be provided externally.
The main functional blocks of the BDLC module are explained in greater detail in the following
sections.
Use of the BDLC module in message networking fully implements the "SAE Standard J1850 Class
B Data Communication Network Interface" specification.
20.5

Signal Description

20.6

Overview

The BDLC module has a total of 2 external pins.
20.6.1

Detailed Signal Descriptions

20.6.1.1

TXB - BDLC Transmit Pin

The TXB pin serves as the transmit output channel for the BDLC module.
20.6.1.2

RXB - BDLC Receive Pin

The RXB pin serves as the receive input channel for the BDLC module.
20.7

Memory Map and Registers

20.7.1 Overview
This section provides a detailed description of all memory and registers accessible to the end user.
20.7.2

Module Memory Map

Address
MBAR + 0x1300
MBAR + 0x1301
MBAR + 0x1304
MBAR + 0x1305
MBAR + 0x1308
MBAR + 0x1309
MBAR + 0x130C
MBAR + 0x130D
20.7.3

Register Descriptions

20.7.3.1 BDLC Control Register 1 (DLCBCR1)—MBAR + 0x1300
This register is used to configure and control the BDLC module.
Freescale Semiconductor
NOTE
Table 20-1. Module Memory Map
Use
BDLC Control Register 1 (DLCBCR1)
BDLC State Vector Register (DLCBSVR)
BDLC Control Register 2 (DLCBCR2)
BDLC Data Register (DLCBDR)
BDLC Analog Round Trip Delay Register (DLCBARD)
BDLC Rate Select Register (DLCBRSR)
BDLC Control Register (DLCSCR)
BDLC Status Register (DLCBSTAT)
MPC5200B Users Guide, Rev. 1
Signal Description
Access
R/W
R
R/W
R/W
R/W
R/W
R/W
R
20-5
