Freescale Semiconductor MPC8349EA MDS Getting Started Manual

HW Getting Started Guide
MPC8349EA MDS
Processor Board
Nov 2006: Rev. A
Contents
Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
About This Document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Required Reading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Definitions, AcroRev. And Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Step 1: Check HW kit contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Step 2: Connect plastic spacers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Step 3: Check Switches and Jumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Step 4: Assemble and connect the power supply kit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Step 5: Perform initial board power up. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Step 6: Connect the JTAG connectivity unit to the board. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Step 7: Attach remaining cables to the board according to your development needs. . . . . . . . . . . . . . . . . . . . . . 7
About This Document
This document shows how to connect the MPC8349EA MDS processor board and verify its basic operation, in a step by step
format. Settings for switches and jumpers are shown, as well as instructions for connecting peripheral devices. In addition,
instructions for connecting the MPC8349EA MDS processor board to an Integrated Development Environment (IDE), such as
®
Freescale's CodeWarrior are included, but instructions for working with the IDE are beyond the scope of this document. This
version of the board has a faster DDR2 (400MHz), and a flash memory of 32MB.
Required Reading
It is assumed that the reader is familiar with the MPC8349EA chip, and the contents of the MPC8349EA Reference Manual.
Definitions, AcroRev. And Abbreviations
BCSR board control and status register
BMS boot memory space
CFG_RS bit in RCW register
CLKDIV clock division
CLKIN clock input
COP debug port in PowerPC
DDR double data rate DRAM
DIP dual in-line package
I2C Philips serial port
JTAG IEEE standard 1149.1
MPC8349EA MDS Processor Board HW Getting Started Guide, Rev. A
Freescale Semiconductor
LED light emitting diode
PCI peripheral component interconnect
PCI_SYNC_OUT chip pin
PIB platform I/O board
PLL phase lock loop
RCW reset configuration words
ROM read-only memory
SHMOO sweep test (of frequency and core voltage)
TLE bit in RCW register
TSEC triple speed ethernet controller
