18.5.21 USARTn_IRCTRL - IrDA Control Register

Offset
0x050
Reset
Access
Name
Bit Name
31:12 Reserved
11:8 IRPRSSEL
A PRS can be used as input to the pulse modulator instead of TX. This value selects the channel to use.
Value
0
1
2
3
4
5
6
7
8
9
10
11
7 IRPRSEN
Enable the PRS channel selected by IRPRSSEL as input to IrDA module instead of TX.
6:4 Reserved
3 IRFILT
Set to enable filter on IrDA demodulator.
Value
0
1
silabs.com | Building a more connected world.
USART - Universal Synchronous Asynchronous Receiver/Transmitter
Reset Access Description
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0x0 RW IrDA PRS Channel Select
Mode Description
PRSCH0 PRS Channel 0 selected
PRSCH1 PRS Channel 1 selected
PRSCH2 PRS Channel 2 selected
PRSCH3 PRS Channel 3 selected
PRSCH4 PRS Channel 4 selected
PRSCH5 PRS Channel 5 selected
PRSCH6 PRS Channel 6 selected
PRSCH7 PRS Channel 7 selected
PRSCH8 PRS Channel 8 selected
PRSCH9 PRS Channel 9 selected
PRSCH10 PRS Channel 10 selected
PRSCH11 PRS Channel 11 selected
0 RW IrDA PRS Channel Enable
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0 RW IrDA RX Filter
Description
No filter enabled
Filter enabled. IrDA pulse must be high for at least 4 consecutive clock
cycles to be detected
Bit Position
Reference Manual
1.2 Conven-
1.2 Conven-
Rev. 1.1 | 590
