Lesense_Bufx_Data - Scan Results (Async Reg) - Silicon Laboratories EFR32xG14 Wireless Gecko Reference Manual

Bit Name
12:8 NEXTSTATE
Index of next state to be entered if the sensor state equals COMP
7:4 MASK
Set bit X to exclude sensor X from evaluation.
3:0 COMP
State transition is triggered when sensor state equals COMP

28.5.27 LESENSE_BUFx_DATA - Scan Results (Async Reg)

For more information about asynchronous registers see
Offset
0x200
Reset
Access
Name
Bit Name
31:20 Reserved
19:16 DATASRC
This bitfield contains the channel index for the sensor result in DATA.
15:0 DATA
This bitfield contains the sensor result.
silabs.com | Building a more connected world.
Reset Access Description
0xXX RW Next State Index
0xX RW Sensor Mask
0xX RW Sensor Compare Value
4.3 Access to Low Energy Peripherals (Asynchronous
Reset Access Description
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0xX R Result Data Source
0xXXXX RWH Scan Result Buffer
LESENSE - Low Energy Sensor Interface
Bit Position
Reference Manual
Registers).
1.2 Conven-
Rev. 1.1 | 993
