26.5.3 ADCn_STATUS - Status Register

Offset
0x00C
Reset
Access
Name
Bit Name
31:18 Reserved
17 SCANDV
SCANCTRLX_DVL # of scan conversion data results are available in Scan FIFO.
16 SINGLEDV
SINGLECTRLX_DVL # of single channel conversion results are available in Single FIFO.
15:13 Reserved
12 WARM
ADC is warmed up.
11:10 PROGERR
Programming Error Status
Mode
BUSCONF
NEGSELCONF
9 SCANREFWARM
Reference selected for scan mode is warmed up.
8 SINGLEREFWARM
Reference selected for single channel mode is warmed up.
7:3 Reserved
2 SCANPENDING
Indicates that either an external scan (e.g., lesense triggered) or a PRS/software triggered scan has gone pending. SCAN-
PENDIF and SCANEXTPENDIF show which one of two went pending.
1 SCANACT
Scan sequence is active or has pending conversions.
silabs.com | Building a more connected world.
Reset Access Description
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0 R Scan Data Valid
0 R Single Channel Data Valid
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0 R ADC Warmed Up
0x0 R Programming Error Status
Value Description
x1 APORT reported a BUS Conflict.
1x SINGLECTRL's NEGSEL choice is invalid with respect to POSSEL
choice. Occurs when two X channels or two Y channels are selected.
0 R Scan Reference Warmed Up
0 R Single Channel Reference Warmed Up
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0 R Scan Conversion Pending
0 R Scan Conversion Active
Bit Position
Reference Manual
ADC - Analog to Digital Converter
1.2 Conven-
1.2 Conven-
1.2 Conven-
Rev. 1.1 | 876
