13.5.6 RTCC_DATE - Date Register (Async Reg)

For more information about asynchronous registers see
Offset
0x014
Reset
Access
Name
Bit Name
31:27 Reserved
26:24 DAYOW
Shows the day of week counter. Register can not be written and will be read as zero when RTCC_CTRL_CNTMODE =
NORMAL.
23:20 YEART
Shows the tens part of the year counter. Register can not be written and will be read as zero when
RTCC_CTRL_CNTMODE = NORMAL.
19:16 YEARU
Shows the unit part of the year counter. Register can not be written and will be read as zero when
RTCC_CTRL_CNTMODE = NORMAL.
15:13 Reserved
12 MONTHT
Shows the tens part of the month counter. Register can not be written and will be read as zero when
RTCC_CTRL_CNTMODE = NORMAL.
11:8 MONTHU
Shows the unit part of the month counter. Register can not be written and will be read as zero when
RTCC_CTRL_CNTMODE = NORMAL.
7:6 Reserved
5:4 DAYOMT
Shows the tens part of the day of month counter. Register can not be written and will be read as zero when
RTCC_CTRL_CNTMODE = NORMAL.
3:0 DAYOMU
Shows the unit part of the day of month counter. Register can not be written and will be read as zero when
RTCC_CTRL_CNTMODE = NORMAL.
silabs.com | Building a more connected world.
4.3 Access to Low Energy Peripherals (Asynchronous
Reset Access Description
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0x0 RWH Day of Week
0x0 RWH Year, Tens
0x0 RWH Year, Units
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0 RWH Month, Tens
0x0 RWH Month, Units
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0x0 RWH Day of Month, Tens
0x0 RWH Day of Month, Units
RTCC - Real Time Counter and Calendar
Bit Position
Reference Manual
Registers).
1.2 Conven-
1.2 Conven-
1.2 Conven-
Rev. 1.1 | 392
