21.5.8 LETIMERn_REP1 - Repeat Counter Register 1 (Async Reg)

For more information about asynchronous registers see
Offset
0x01C
Reset
Access
Name
Bit Name
31:8 Reserved
7:0 REP1
Optional repeat counter or buffer for REP0.

21.5.9 LETIMERn_IF - Interrupt Flag Register

Offset
0x020
Reset
Access
Name
Bit Name
31:5 Reserved
4 REP1
Set when repeat counter 1 reaches zero.
3 REP0
Set when repeat counter 0 reaches zero or when the REP1 interrupt flag is loaded into the REP0 interrupt flag.
2 UF
Set on LETIMER underflow.
1 COMP1
Set when LETIMER reaches the value of COMP1.
0 COMP0
Set when LETIMER reaches the value of COMP0.
silabs.com | Building a more connected world.
4.3 Access to Low Energy Peripherals (Asynchronous
Reset Access Description
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0x00 RWH Repeat Counter 1
Reset Access Description
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0 R Repeat Counter 1 Interrupt Flag
0 R Repeat Counter 0 Interrupt Flag
0 R Underflow Interrupt Flag
0 R Compare Match 1 Interrupt Flag
0 R Compare Match 0 Interrupt Flag
Bit Position
Bit Position
Reference Manual
LETIMER - Low Energy Timer
Registers).
1.2 Conven-
1.2 Conven-
Rev. 1.1 | 734
