Silicon Laboratories EFR32xG14 Wireless Gecko Reference Manual page 743

Bit Name
2
3
17:16 Reserved
15:12 PRSCLEARSEL
Determines which PRS input can clear the LETIMER.
Value
0
1
2
3
4
5
6
7
8
9
10
11
11:10 Reserved
9:6 PRSSTOPSEL
Determines which PRS input can stop the LETIMER.
Value
0
1
2
3
4
5
6
7
8
9
10
11
silabs.com | Building a more connected world.
Reset Access Description
FALLING Falling edge of selected PRS input can start the LETIMER
BOTH Both the rising or falling edge of the selected PRS input can start the
LETIMER
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0x0 RW PRS Clear Select
Mode Description
PRSCH0 PRS Channel 0 selected as input
PRSCH1 PRS Channel 1 selected as input
PRSCH2 PRS Channel 2 selected as input
PRSCH3 PRS Channel 3 selected as input
PRSCH4 PRS Channel 4 selected as input
PRSCH5 PRS Channel 5 selected as input
PRSCH6 PRS Channel 6 selected as input
PRSCH7 PRS Channel 7 selected as input
PRSCH8 PRS Channel 8 selected as input
PRSCH9 PRS Channel 9 selected as input
PRSCH10 PRS Channel 10 selected as input
PRSCH11 PRS Channel 11 selected as input
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0x0 RW PRS Stop Select
Mode Description
PRSCH0 PRS Channel 0 selected as input
PRSCH1 PRS Channel 1 selected as input
PRSCH2 PRS Channel 2 selected as input
PRSCH3 PRS Channel 3 selected as input
PRSCH4 PRS Channel 4 selected as input
PRSCH5 PRS Channel 5 selected as input
PRSCH6 PRS Channel 6 selected as input
PRSCH7 PRS Channel 7 selected as input
PRSCH8 PRS Channel 8 selected as input
PRSCH9 PRS Channel 9 selected as input
PRSCH10 PRS Channel 10 selected as input
PRSCH11 PRS Channel 11 selected as input
Reference Manual
LETIMER - Low Energy Timer
1.2 Conven-
1.2 Conven-
Rev. 1.1 | 743
