Prs_Routeloc0 - I/O Routing Location Register - Silicon Laboratories EFR32xG14 Wireless Gecko Reference Manual

15.5.4 PRS_ROUTELOC0 - I/O Routing Location Register

Offset
0x010
Reset
Access
Name
Bit Name
31:30 Reserved
29:24 CH3LOC
Decides the location of the channel I/O pin
Value
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
23:22 Reserved
21:16 CH2LOC
Decides the location of the channel I/O pin
Value
0
1
2
silabs.com | Building a more connected world.
Reset Access Description
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0x00 RW I/O Location
Mode Description
LOC0 Location 0
LOC1 Location 1
LOC2 Location 2
LOC3 Location 3
LOC4 Location 4
LOC5 Location 5
LOC6 Location 6
LOC7 Location 7
LOC8 Location 8
LOC9 Location 9
LOC10 Location 10
LOC11 Location 11
LOC12 Location 12
LOC13 Location 13
LOC14 Location 14
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0x00 RW I/O Location
Mode Description
LOC0 Location 0
LOC1 Location 1
LOC2 Location 2
Bit Position
Reference Manual
PRS - Peripheral Reflex System
1.2 Conven-
1.2 Conven-
