Silicon Laboratories EFR32xG14 Wireless Gecko Reference Manual page 975

Bit Name
15:14 CH7
This bitfield determines how the channel is configured during the idle phase
Value
0
1
2
3
13:12 CH6
This bitfield determines how the channel is configured during the idle phase
Value
0
1
2
3
11:10 CH5
This bitfield determines how the channel is configured during the idle phase
Value
0
1
2
3
9:8 CH4
This bitfield determines how the channel is configured during the idle phase
Value
0
1
2
3
7:6 CH3
This bitfield determines how the channel is configured during the idle phase
Value
0
silabs.com | Building a more connected world.
Reset Access Description
0x0 RW Channel 7 Idle Phase Configuration
Mode Description
DISABLE CH7 output is disabled in idle phase
HIGH CH7 output is high in idle phase
LOW CH7 output is low in idle phase
DAC CH7 output is connected to VDAC output in idle phase. Note that this
mode is only available on channels 4, 5, 7, 10, 12, 13
0x0 RW Channel 6 Idle Phase Configuration
Mode Description
DISABLE CH6 output is disabled in idle phase
HIGH CH6 output is high in idle phase
LOW CH6 output is low in idle phase
DAC CH6 output is connected to VDAC output in idle phase. Note that this
mode is only available on channels 4, 5, 7, 10, 12, 13
0x0 RW Channel 5 Idle Phase Configuration
Mode Description
DISABLE CH5 output is disabled in idle phase
HIGH CH5 output is high in idle phase
LOW CH5 output is low in idle phase
DAC CH5 output is connected to VDAC output in idle phase. Note that this
mode is only available on channels 4, 5, 7, 10, 12, 13
0x0 RW Channel 4 Idle Phase Configuration
Mode Description
DISABLE CH4 output is disabled in idle phase
HIGH CH4 output is high in idle phase
LOW CH4 output is low in idle phase
DAC CH4 output is connected to VDAC output in idle phase. Note that this
mode is only available on channels 4, 5, 7, 10, 12, 13
0x0 RW Channel 3 Idle Phase Configuration
Mode Description
DISABLE CH3 output is disabled in idle phase
LESENSE - Low Energy Sensor Interface
Reference Manual
Rev. 1.1 | 975
