16.5.15 PCNTn_INPUT - PCNT Input Register

Offset
0x068
Reset
Access
Name
Bit Name
31:12 Reserved
11 S1PRSEN
When set, the PRS channel is selected as input to S1IN.
10 Reserved
9:6 S1PRSSEL
Select PRS channel as input to S1IN.
Value
0
1
2
3
4
5
6
7
8
9
10
11
5 S0PRSEN
When set, the PRS channel is selected as input to S0IN.
4 Reserved
3:0 S0PRSSEL
Select PRS channel as input to S0IN.
Value
silabs.com | Building a more connected world.
Reset Access Description
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0 RW S1IN PRS Enable
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0x0 RW S1IN PRS Channel Select
Mode Description
PRSCH0 PRS Channel 0 selected.
PRSCH1 PRS Channel 1 selected.
PRSCH2 PRS Channel 2 selected.
PRSCH3 PRS Channel 3 selected.
PRSCH4 PRS Channel 4 selected.
PRSCH5 PRS Channel 5 selected.
PRSCH6 PRS Channel 6 selected.
PRSCH7 PRS Channel 7 selected.
PRSCH8 PRS Channel 8 selected.
PRSCH9 PRS Channel 9 selected.
PRSCH10 PRS Channel 10 selected.
PRSCH11 PRS Channel 11 selected.
0 RW S0IN PRS Enable
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0x0 RW S0IN PRS Channel Select
Mode Description
Bit Position
Reference Manual
PCNT - Pulse Counter
1.2 Conven-
1.2 Conven-
1.2 Conven-
Rev. 1.1 | 476
