Silicon Laboratories EFR32xG14 Wireless Gecko Reference Manual page 974

Bit Name
0
1
2
3
23:22 CH11
This bitfield determines how the channel is configured during the idle phase
Value
0
1
2
3
21:20 CH10
This bitfield determines how the channel is configured during the idle phase
Value
0
1
2
3
19:18 CH9
This bitfield determines how the channel is configured during the idle phase
Value
0
1
2
3
17:16 CH8
This bitfield determines how the channel is configured during the idle phase
Value
0
1
2
3
silabs.com | Building a more connected world.
Reset Access Description
DISABLE CH12 output is disabled in idle phase
HIGH CH12 output is high in idle phase
LOW CH12 output is low in idle phase
DAC CH12 output is connected to VDAC output in idle phase. Note that this
mode is only available on channels 4, 5, 7, 10, 12, 13
0x0 RW Channel 11 Idle Phase Configuration
Mode Description
DISABLE CH11 output is disabled in idle phase
HIGH CH11 output is high in idle phase
LOW CH11 output is low in idle phase
DAC CH11 output is connected to VDAC output in idle phase. Note that this
mode is only available on channels 4, 5, 7, 10, 12, 13
0x0 RW Channel 10 Idle Phase Configuration
Mode Description
DISABLE CH10 output is disabled in idle phase
HIGH CH10 output is high in idle phase
LOW CH10 output is low in idle phase
DAC CH10 output is connected to VDAC output in idle phase. Note that this
mode is only available on channels 4, 5, 7, 10, 12, 13
0x0 RW Channel 9 Idle Phase Configuration
Mode Description
DISABLE CH9 output is disabled in idle phase
HIGH CH9 output is high in idle phase
LOW CH9 output is low in idle phase
DAC CH9 output is connected to VDAC output in idle phase. Note that this
mode is only available on channels 4, 5, 7, 10, 12, 13
0x0 RW Channel 8 Idle Phase Configuration
Mode Description
DISABLE CH8 output is disabled in idle phase
HIGH CH8 output is high in idle phase
LOW CH8 output is low in idle phase
DAC CH8 output is connected to VDAC output in idle phase. Note that this
mode is only available on channels 4, 5, 7, 10, 12, 13
LESENSE - Low Energy Sensor Interface
Reference Manual
Rev. 1.1 | 974
