10.5.5 EMU_CMD - Command Register

Offset
0x010
Reset
Access
Name
Bit Name
31:7 Reserved
6 EM01VSCALE2
Start EM01 voltage scaling to Voltage Scale Level 2. Write to this register will trigger voltage scaling to Voltage Scale Level
2 followed by an VSCALEDONE interrupt
5 Reserved
4 EM01VSCALE0
Start EM01 voltage scaling to Voltage Scale Level 0. Write to this register will trigger voltage scaling to Voltage Scale Level
0 followed by an VSCALEDONE interrupt
3:1 Reserved
0 EM4UNLATCH
When entering EM4, several registers will be latched in order to maintain constant functionality throughout EM4. Upon
wakeup, these registers will be reset and can have contradictory values to the latched values. To ensure a seamless transi-
tion from EM4 to EM0, the unlatch command should be given after properly reconfiguring these latched registers. The un-
latch command can be executed after any reset condition but is only needed after EM4 wakeup.
silabs.com | Building a more connected world.
Reset Access Description
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0 W1 EM01 Voltage Scale Command to Scale to Voltage Scale Level 2
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0 W1 EM01 Voltage Scale Command to Scale to Voltage Scale Level 0
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0 W1 EM4 Unlatch
Bit Position
Reference Manual
EMU - Energy Management Unit
1.2 Conven-
1.2 Conven-
1.2 Conven-
