21.3.5 PRS Output

The LETIMER outputs can be routed out onto the PRS system. LETn_O0 can be routed to PRS channel 0, and LETn_O1 can be rout-
ed to PRS channel 1. Enabling the PRS connection can be done by setting SOURCESEL to LETIMERx and SIGSEL to LETIMERxCHn
in PRS_CHx_CTRL. The PRS register description can be found in

21.3.6 Examples

This section presents a couple of usage examples for the LETIMER.
silabs.com | Building a more connected world.
UFOA0 = 10
UFOA1 = 10
REP0 = 2
REP1 = 7 REP0 = 3
START START
LETn_O0
LETn_O1
Figure 21.10. LETIMER Dual Output
REP0 = 2
REP1 = 3
START
