11.5.13 CMU_CMD - Command Register

Offset
0x064
Reset
Access
Name
Bit Name
31:6 Reserved
5 HFXOSHUNTOPT-
START
Starts the HFXO Shunt Current Optimization and runs it one time.
4 HFXOPEAKDET-
START
Starts the HFXO peak detection and runs it one time.
3:2 Reserved
1 CALSTOP
Stops the calibration counters.
0 CALSTART
Starts the calibration, effectively loading the CMU_CALCNT into the down-counter and start decrementing.
silabs.com | Building a more connected world.
Reset Access Description
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0 W1 HFXO Shunt Current Optimization Start
0 W1 HFXO Peak Detection Start
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0 W1 Calibration Stop
0 W1 Calibration Start
Bit Position
Reference Manual
CMU - Clock Management Unit
1.2 Conven-
1.2 Conven-
Rev. 1.1 | 328
