31.6.4 CRYPTO_STATUS - Status Register

Offset
0x010
Reset
Access
Name
Bit Name
31:3 Reserved
2 DMAACTIVE
This bit indicates that the AES module is waiting for a DMA transfer to complete.
1 INSTRRUNNING
This bit indicates that the AES module busy executing an instruction. The origin of the instruction is either through CRYP-
TO_CMD or due to a running SEQUENCE.
0 SEQRUNNING
This bit indicates that the AES module is running an encryption/decryption SEQUENCE.
