31.6.9 CRYPTO_SEQCTRL - Sequence Control

Offset
0x030
Reset
Access
Name
Bit Name
31 HALT
Allows stepping through CRYPTO instructions in the sequence for debugging.
30 Reserved
29 DMA1PRESA
Set to write skipped bytes back on next DMA1WR triggered write. Use this together with DMA1SKIP to enable in-place con-
versions with CRYPTO
28 DMA0PRESA
Set to write skipped bytes back on next DMA0WR triggered write. Use this together with DMA0SKIP to enable in-place con-
versions with CRYPTO
27:26 DMA1SKIP
Set to number of bytes to exclude from data received by next DMA1RD insruction
25:24 DMA0SKIP
Set to number of bytes to exclude from data received by next DMA0RD insruction
23:22 Reserved
21:20 BLOCKSIZE
Defines the width of blocks processed in each iteration of a sequence running on a dataset (see related note in
31.4.3 Repeated Sequence)
Value
0
1
2
19:14 Reserved
13:0 LENGTHA
This field sets the number of bytes to be handled during the repeated sequence. Set it to the exact number of bytes. If the
number is not a multiple of BLOCKSIZE, the last data block is zero-padded. Format is unsigned integer.
silabs.com | Building a more connected world.
Reset Access Description
0 RW Halt Sequence
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0 RW DMA1 Preserve a
0 RW DMA0 Preserve a
0x0 RWH DMA1 Skip
0x0 RWH DMA0 Skip
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0x0 RW Size of Data Blocks
Mode Description
16BYTES A block is 16 bytes long
32BYTES A block is 32 bytes long
64BYTES A block is 64 bytes long
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0x0000 RWH Buffer Length a in Bytes
Bit Position
Reference Manual
CRYPTO - Crypto Accelerator
1.2 Conven-
1.2 Conven-
1.2 Conven-
Rev. 1.1 | 1061
