Bit Name
5 QDM
This bit sets the mode for the quadrature decoder.
Value
0
1
4 OSMEN
Enable/disable one shot mode.
3 SYNC
When this bit is set, the Timer is started/stopped/reloaded by start/stop/reload commands in the other timers
Value
0
1
2 Reserved
1:0 MODE
These bits set the counting mode for the Timer. Note, when Quadrature Decoder Mode is selected (MODE = 'b11), the
CLKSEL is don't care. The Timer is clocked by the Decoder Mode clock output.
Value
0
1
2
3
silabs.com | Building a more connected world.
Reset Access Description
0 RW Quadrature Decoder Mode Selection
Mode Description
X2 X2 mode selected
X4 X4 mode selected
0 RW One-shot Mode Enable
0 RW Timer Start/Stop/Reload Synchronization
Description
Timer is not started/stopped/reloaded by other timers
Timer is started/stopped/reloaded by other timers
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0x0 RW Timer Mode
Mode Description
UP Up-count mode
DOWN Down-count mode
UPDOWN Up/down-count mode
QDEC Quadrature decoder mode
Reference Manual
TIMER/WTIMER - Timer/Counter
1.2 Conven-
