Lesense_Chx_Eval - Scan Configuration (Async Reg) - Silicon Laboratories EFR32xG14 Wireless Gecko Reference Manual

28.5.30 LESENSE_CHx_EVAL - Scan Configuration (Async Reg)

For more information about asynchronous registers see
Offset
0x248
Reset
Access
Name
Bit Name
31:23 Reserved
22:21 MODE
Select which evaluation mode to be used on the measurement result
Value
0
1
2
20 SCANRESINV
If set, the bit stored in SCANRES will be inverted.
19:18 STRSAMPLE
If set, the sensor sample value will be stored and available in the result buffer
Value
0
1
2
17 DECODE
If set, the result from this channel will be shifted into the decoder register.
16 COMP
Set compare mode for threshold comparisons (CHx_INTERACT_SAMPLE != ACMP and CHx_EVAL_MODE == THRES).
Value
0
1
silabs.com | Building a more connected world.
4.3 Access to Low Energy Peripherals (Asynchronous
Reset Access Description
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0xX RW Configure Evaluation Mode
Mode Description
THRES Threshold comparison is used to evaluate sensor result
SLIDINGWIN Sliding window is used to evaluate sensor result
STEPDET Step detection is used to evaluate sensor result
X RW Enable Inversion of Result
0xX RW Enable Storing of Sensor Sample in Result Buffer
Mode Description
DISABLE Nothing will be stored in the result buffer.
DATA The sensor sample data will be stored in the result buffer.
DATASRC The data source (i.e., the channel) will be stored alongside the sensor
sample data.
X RW Send Result to Decoder
X RW Select Mode for Threshold Comparison
Mode Description
LESS Comparison evaluates to 1 if sensor data is less than COMPTHRES.
GE Comparison evaluates to 1 if sensor data is greater than or equal to
COMPTHRES.
LESENSE - Low Energy Sensor Interface
Bit Position
Reference Manual
Registers).
1.2 Conven-
