Prs_Routeloc2 - I/O Routing Location Register - Silicon Laboratories EFR32xG14 Wireless Gecko Reference Manual

15.5.6 PRS_ROUTELOC2 - I/O Routing Location Register

Offset
0x018
Reset
Access
Name
Bit Name
31:30 Reserved
29:24 CH11LOC
Decides the location of the channel I/O pin
Value
0
1
2
3
4
5
23:22 Reserved
21:16 CH10LOC
Decides the location of the channel I/O pin
Value
0
1
2
3
4
5
15:14 Reserved
13:8 CH9LOC
Decides the location of the channel I/O pin
Value
0
silabs.com | Building a more connected world.
Reset Access Description
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0x00 RW I/O Location
Mode Description
LOC0 Location 0
LOC1 Location 1
LOC2 Location 2
LOC3 Location 3
LOC4 Location 4
LOC5 Location 5
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0x00 RW I/O Location
Mode Description
LOC0 Location 0
LOC1 Location 1
LOC2 Location 2
LOC3 Location 3
LOC4 Location 4
LOC5 Location 5
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0x00 RW I/O Location
Mode Description
LOC0 Location 0
Bit Position
Reference Manual
PRS - Peripheral Reflex System
1.2 Conven-
1.2 Conven-
1.2 Conven-
Rev. 1.1 | 434
