17.3.7.2 Interactions
2
Whenever the I C module is waiting for interaction from software, it holds the bus clock SCL low, freezing all bus activities, and the
BUSHOLD interrupt flag in I2Cn_IF is set. The action(s) required by software depends on the current state the of the I
state can be read from the I2Cn_STATE register.
As an example, Table 17.3 I2C Master Transmitter on page 491
Master Transmitter, i.e., a master that transmits data to a slave. As seen in the table, when a start condition has been transmitted, a
requirement is that there is an address and an R/W bit in the transmit buffer. If the transmit buffer is empty, then the BUSHOLD interrupt
flag is set, and the bus is held until data becomes available in the buffer. While waiting for the address, I2Cn_STATE has a value 0x57,
which can be used to identify exactly what the I
Note:
The bus would never stop at state 0x57 if the address was available in the transmit buffer.
The different interactions used by the I
2
tized order. If the I C module is in such a state that multiple courses of action are possible, then the action chosen is the one that has
the highest priority. For example, after sending out a START, if an address is present in the buffer and a STOP is also pending, then the
2
I C will send out the STOP since it has the higher priority.
Interaction
STOP*
ABORT
CONT*
NACK*
ACK*
ADDR+W -> TXDATA
ADDR+R -> TXDATA
START*
TXDATA/ TXDOUBLE
RXDATA/ RXDOUBLE
None
The commands marked with a * in
required. When such a command is issued before it can be used/consumed by the I
which can be read from the STATUS register. A pending START command can for instance be identified by PSTART having a high
value.
2
Whenever the I C module requires an interaction, it checks the pending commands. If one or a combination of these can fulfill an inter-
action, they are consumed by the module and the transmission continues without setting the BUSHOLD interrupt flag in I2Cn_IF to get
an interaction from software. The pending status of a command goes low when it is consumed.
