11.5.46 CMU_ROUTELOC0 - I/O Routing Location Register

Offset
0x174
Reset
Access
Name
Bit Name
31:14 Reserved
13:8 CLKOUT1LOC
Decides the location of the CLKOUT1.
Value
0
1
2
3
4
5
6
7
7:6 Reserved
5:0 CLKOUT0LOC
Decides the location of the CMU CLKOUT0.
Value
0
1
2
3
4
5
6
7
silabs.com | Building a more connected world.
Reset Access Description
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0x00 RW I/O Location
Mode Description
LOC0 Location 0
LOC1 Location 1
LOC2 Location 2
LOC3 Location 3
LOC4 Location 4
LOC5 Location 5
LOC6 Location 6
LOC7 Location 7
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0x00 RW I/O Location
Mode Description
LOC0 Location 0
LOC1 Location 1
LOC2 Location 2
LOC3 Location 3
LOC4 Location 4
LOC5 Location 5
LOC6 Location 6
LOC7 Location 7
Bit Position
Reference Manual
CMU - Clock Management Unit
1.2 Conven-
1.2 Conven-
Rev. 1.1 | 361
