28.4 Register Map

The offset register address is relative to the registers base address.
Offset Name
0x000 LESENSE_CTRL
0x004 LESENSE_TIMCTRL
0x008 LESENSE_PERCTRL
0x00C LESENSE_DECCTRL
0x010 LESENSE_BIASCTRL
0x014 LESENSE_EVALCTRL
0x018 LESENSE_PRSCTRL
0x01C LESENSE_CMD
0x020 LESENSE_CHEN
0x024 LESENSE_SCANRES
0x028 LESENSE_STATUS
0x02C LESENSE_PTR
0x030 LESENSE_BUFDATA
0x034 LESENSE_CURCH
0x038 LESENSE_DECSTATE
0x03C LESENSE_SENSORSTATE
0x040 LESENSE_IDLECONF
0x044 LESENSE_ALTEXCONF
0x050 LESENSE_IF
0x054 LESENSE_IFS
0x058 LESENSE_IFC
0x05C LESENSE_IEN
0x060 LESENSE_SYNCBUSY
0x064 LESENSE_ROUTEPEN
0x100 LESENSE_ST0_TCONFA
0x104 LESENSE_ST0_TCONFB
... LESENSE_STx_TCONFA
... LESENSE_STx_TCONFB
0x1F8 LESENSE_ST31_TCONFA
0x1FC LESENSE_ST31_TCONFB
0x200 LESENSE_BUF0_DATA
... LESENSE_BUFx_DATA
0x23C LESENSE_BUF15_DATA
0x240 LESENSE_CH0_TIMING
0x244 LESENSE_CH0_INTERACT
silabs.com | Building a more connected world.
Type Description
RW Control Register
RW Timing Control Register
RW Peripheral Control Register
RW Decoder Control Register
RW Bias Control Register
RW LESENSE Evaluation Control
RW PRS Control Register
W1 Command Register
RW Channel Enable Register
RWH Scan Result Register
R Status Register
R Result Buffer Pointers
R(a) Result Buffer Data Register
R Current Channel Index
RWH Current Decoder State
RWH Decoder Input Register
RW GPIO Idle Phase Configuration
RW Alternative Excite Pin Configuration
R Interrupt Flag Register
W1 Interrupt Flag Set Register
(R)W1 Interrupt Flag Clear Register
RW Interrupt Enable Register
R Synchronization Busy Register
RW I/O Routing Register
RW State Transition Configuration a
RW State Transition Configuration B
RW State Transition Configuration a
RW State Transition Configuration B
RW State Transition Configuration a
RW State Transition Configuration B
RWH Scan Results
RWH Scan Results
RWH Scan Results
RW Scan Configuration
RW Scan Configuration
