31.6.18 CRYPTO_SEQ3 - Sequence Register 3

Offset
0x05C
Reset
Access
Name
Bit Name
31:24 INSTR15
Sequence instruction. See INSTR in CRYPTO_CMD for a possible values.
23:16 INSTR14
Sequence instruction. See INSTR in CRYPTO_CMD for a possible values.
15:8 INSTR13
Sequence instruction. See INSTR in CRYPTO_CMD for a possible values.
7:0 INSTR12
Sequence instruction. See INSTR in CRYPTO_CMD for a possible values.
31.6.19 CRYPTO_SEQ4 - Sequence Register 4
Offset
0x060
Reset
Access
Name
Bit Name
31:24 INSTR19
Sequence instruction. See INSTR in CRYPTO_CMD for a possible values.
23:16 INSTR18
Sequence instruction. See INSTR in CRYPTO_CMD for a possible values.
15:8 INSTR17
Sequence instruction. See INSTR in CRYPTO_CMD for a possible values.
7:0 INSTR16
Sequence instruction. See INSTR in CRYPTO_CMD for a possible values.
silabs.com | Building a more connected world.
Reset Access Description
0x00 RW Sequence Instruction 15
0x00 RW Sequence Instruction 14
0x00 RW Sequence Instruction 13
0x00 RW Sequence Instruction 12
Reset Access Description
0x00 RW Sequence Instruction 19
0x00 RW Sequence Instruction 18
0x00 RW Sequence Instruction 17
0x00 RW Sequence Instruction 16
Bit Position
Bit Position
