Bit Name
8
9
10
11
9 Reserved
8 INPUT
Select input to the LESENSE decoder
Value
0
1
7 PRSCNT
When set, decoder PRS0 and PRS1 will be used to produce output which can be used by a PCNT to count up or down.
6 HYSTIRQ
When set, hysteresis is enabled in the decoder, suppressing interrupt requests.
5 HYSTPRS2
When set, hysteresis is enabled in the decoder, suppressing changes on PRS channel 2
4 HYSTPRS1
When set, hysteresis is enabled in the decoder, suppressing changes on PRS channel 1
3 HYSTPRS0
When set, hysteresis is enabled in the decoder, suppressing changes on PRS channel 0
2 INTMAP
When set, a transition from state x in the decoder will set interrupt flag CH[x mod 16]
1 ERRCHK
When set, the decoder checks the current state in addition to the states defined in TCONF
0 DISABLE
When set, the decoder is disabled. When disabled the decoder will keep its current state
silabs.com | Building a more connected world.
Reset Access Description
PRSCH8 PRS Channel 8 selected as input
PRSCH9 PRS Channel 9 selected as input
PRSCH10 PRS Channel 10 selected as input
PRSCH11 PRS Channel 11 selected as input
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0 RW LESENSE Decoder Input Configuration
Mode Description
SENSORSTATE The SENSORSTATE register is used as input to the decoder.
PRS PRS channels are used as input to the decoder.
0 RW Enable Count Mode on Decoder PRS Channels 0 and 1
0 RW Enable Decoder Hysteresis on Interrupt Requests
0 RW Enable Decoder Hysteresis on PRS2 Output
0 RW Enable Decoder Hysteresis on PRS1 Output
0 RW Enable Decoder Hysteresis on PRS0 Output
0 RW Enable Decoder to Channel Interrupt Mapping
0 RW Enable Check of Current State
0 RW Disable the Decoder
