25.5.14 ACMPn_EXTIFCTRL - External Override Interface Control

Offset
0x048
Reset
Access
Name
Bit Name
31:8 Reserved
7:4 APORTSEL
Decides which APORT(s) the ACMP will use when controlled by an external module.
Value
0
1
2
3
4
5
6
7
8
9
10
11
12
13
silabs.com | Building a more connected world.
Reset Access Description
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0x0 RW APORT Selection for External Interface
Mode Description
APORT0X APORT0X used. EXT_BASE = ACMP_INPUTSEL_POS-
SEL_APORT0XCH0.
APORT0Y APORT0Y used. EXT_BASE = ACMP_INPUTSEL_POS-
SEL_APORT0YCH0.
APORT1X APORT1X used. EXT_BASE = ACMP_INPUTSEL_POS-
SEL_APORT1XCH0.
APORT1Y APORT1Y used. EXT_BASE = ACMP_INPUTSEL_POS-
SEL_APORT1XCH0.
APORT1XY APORT1X/Y used. EXT_BASE = ACMP_INPUTSEL_POS-
SEL_APORT1XCH0.
APORT2X APORT2X used. EXT_BASE = ACMP_INPUTSEL_POS-
SEL_APORT2YCH0.
APORT2Y APORT2Y used. EXT_BASE = ACMP_INPUTSEL_POS-
SEL_APORT2YCH0.
APORT2YX APORT2Y/X used. EXT_BASE = ACMP_INPUTSEL_POS-
SEL_APORT2YCH0.
APORT3X APORT3X used. EXT_BASE = ACMP_INPUTSEL_POS-
SEL_APORT3XCH0.
APORT3Y APORT3Y used. EXT_BASE = ACMP_INPUTSEL_POS-
SEL_APORT3XCH0.
APORT3XY APORT3X/Y used. EXT_BASE = ACMP_INPUTSEL_POS-
SEL_APORT3XCH0.
APORT4X APORT4X used. EXT_BASE = ACMP_INPUTSEL_POS-
SEL_APORT4YCH0.
APORT4Y APORT4Y used. EXT_BASE = ACMP_INPUTSEL_POS-
SEL_APORT4YCH0.
APORT4YX APORT4Y/X used. EXT_BASE = ACMP_INPUTSEL_POS-
SEL_APORT4YCH0.
Bit Position
Reference Manual
ACMP - Analog Comparator
1.2 Conven-
Rev. 1.1 | 842
