17.5.3 I2Cn_STATE - State Register

Offset
0x008
Reset
Access
Name
Bit Name
31:8 Reserved
7:5 STATE
The state of any current transmission. Cleared if the I
Value
0
1
2
3
4
5
6
4 BUSHOLD
Set if the bus is currently being held by this I
3 NACKED
Set if a NACK was received and STATE is ADDRACK or DATAACK.
2 TRANSMITTER
Set when operating as a master transmitter or a slave transmitter. When cleared, the system may be operating as a master
receiver, a slave receiver or the current mode is not known.
1 MASTER
Set when operating as an I
0 BUSY
Set when the bus is busy. Whether the I
the MCU comes out of reset, the state of the bus is not known, and thus BUSY is set. Use the ABORT command or a bus
idle timeout to force the I
