Silicon Laboratories EFR32xG14 Wireless Gecko Reference Manual page 701

Bit Name
0
1
2
3
9:8 CMOA
Select output action on compare match.
Value
0
1
2
3
7:5 Reserved
4 COIST
This bit is only used in Output Compare and PWM mode. When this bit is set in Compare or PWM mode, the output is set
high when the counter is disabled. When counting resumes, this value will represent the initial value for the output. If the bit
is cleared, the output will be cleared when the counter is disabled.
3 Reserved
2 OUTINV
Setting this bit inverts the output from the CC channel (Output compare,PWM).
1:0 MODE
These bits select the mode for Compare/Capture channel.
Value
0
1
2
3
silabs.com | Building a more connected world.
Reset Access Description
NONE No action on counter overflow
TOGGLE Toggle output on counter overflow
CLEAR Clear output on counter overflow
SET Set output on counter overflow
0x0 RW Compare Match Output Action
Mode Description
NONE No action on compare match
TOGGLE Toggle output on compare match
CLEAR Clear output on compare match
SET Set output on compare match
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0 RW Compare Output Initial State
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0 RW Output Invert
0x0 RW CC Channel Mode
Mode Description
OFF Compare/Capture channel turned off
INPUTCAPTURE Input capture
OUTPUTCOMPARE Output compare
PWM Pulse-Width Modulation
Reference Manual
TIMER/WTIMER - Timer/Counter
1.2 Conven-
1.2 Conven-
Rev. 1.1 | 701
