20.5.13 TIMERn_ROUTELOC0 - I/O Routing Location Register

Offset
0x034
Reset
Access
Name
Bit Name
31:30 Reserved
29:24 CC3LOC
Decides the location of the CC3 pin.
Value
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
silabs.com | Building a more connected world.
Reset Access Description
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0x00 RW I/O Location
Mode Description
LOC0 Location 0
LOC1 Location 1
LOC2 Location 2
LOC3 Location 3
LOC4 Location 4
LOC5 Location 5
LOC6 Location 6
LOC7 Location 7
LOC8 Location 8
LOC9 Location 9
LOC10 Location 10
LOC11 Location 11
LOC12 Location 12
LOC13 Location 13
LOC14 Location 14
LOC15 Location 15
LOC16 Location 16
LOC17 Location 17
LOC18 Location 18
LOC19 Location 19
LOC20 Location 20
LOC21 Location 21
LOC22 Location 22
Bit Position
