Silicon Laboratories EFR32xG14 Wireless Gecko Reference Manual page 976

Bit Name
1
2
3
5:4 CH2
This bitfield determines how the channel is configured during the idle phase
Value
0
1
2
3
3:2 CH1
This bitfield determines how the channel is configured during the idle phase
Value
0
1
2
3
1:0 CH0
This bitfield determines how the channel is configured during the idle phase
Value
0
1
2
3
silabs.com | Building a more connected world.
Reset Access Description
HIGH CH3 output is high in idle phase
LOW CH3 output is low in idle phase
DAC CH3 output is connected to VDAC output in idle phase. Note that this
mode is only available on channels 4, 5, 7, 10, 12, 13
0x0 RW Channel 2 Idle Phase Configuration
Mode Description
DISABLE CH2 output is disabled in idle phase
HIGH CH2 output is high in idle phase
LOW CH2 output is low in idle phase
DAC CH2 output is connected to VDAC output in idle phase. Note that this
mode is only available on channels 4, 5, 7, 10, 12, 13
0x0 RW Channel 1 Idle Phase Configuration
Mode Description
DISABLE CH1 output is disabled in idle phase
HIGH CH1 output is high in idle phase
LOW CH1 output is low in idle phase
DAC CH1 output is connected to VDAC output in idle phase. Note that this
mode is only available on channels 4, 5, 7, 10, 12, 13
0x0 RW Channel 0 Idle Phase Configuration
Mode Description
DISABLE CH0 output is disabled in idle phase
HIGH CH0 output is high in idle phase
LOW CH0 output is low in idle phase
DAC CH0 output is connected to VDAC output in idle phase. Note that this
mode is only available on channels 4, 5, 7, 10, 12, 13
LESENSE - Low Energy Sensor Interface
Reference Manual
Rev. 1.1 | 976
