28.3.16.2 LC Sensor
Figure 28.16 LC Sensor Setup on page 948
LESENSE can be used to excite and measure the damping factor in LC sensor oscillations. To measure the damping factor, the ACMP
can be used to generate a high output each time the sensor voltage exceeds a certain level. These pulses are counted using an asyn-
chronous counter and compared with the threshold in COMPTHRES in the CHx_EVAL register. If the number of pulses exceeds the
threshold level, the sensor is said to be active, otherwise it is inactive.
how the output pulses from the ACMP correspond to damping of the oscillations. The results from sensor evaluation can automatically
be fed into the decoder in order to keep track of rotations.
LC sensor ACMP output
2,95
2,45
1,95
1,45
0,95
0,45
-0,05
0 10 20 30 40
The following steps show how to configure LESENSE to scan through the four LC sensors 100 times per second.
1. Assuming LFACLK
LESENSE
100Hz.
2. Enable the VDAC and configure it to produce a voltage of Vdd/2.
